PN2222
PN2222
General Purpose Transistor
1
TO-92
1. Emitter 2. Base 3. Collector
NPN Epitaxial Silicon Transistor
Absolute Maximum Ratings
T
a
=25°C unless otherwise noted
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
T
J
T
STG
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Collector Power Dissipation
Junction Temperature
Storage Temperature
Parameter
Value
60
30
5
600
625
150
-55 ~ 150
Units
V
V
V
mA
mW
°C
°C
Electrical Characteristics
T
a
=25°C unless otherwise noted
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
h
FE
V
CE
(sat)
V
BE
(sat)
f
T
C
ob
Parameter
Collector-Base Breakdown Voltage
Collector Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cut-off Current
Emitter Cut-off Current
DC Current Gain
* Collector-Emitter Saturation Voltage
* Base-Emitter Saturation Voltage
Current Gain Bandwidth Product
Output Capacitance
Test Condition
I
C
=10µA, I
E
=0
I
C
=10mA, I
B
=0
I
E
=10µA, I
C
=0
V
CB
=50V, I
E
=0
V
EB
=3V, I
C
=0
V
CE
=10V, I
C
=0.1mA
V
CE
=10V, *I
C
=150mA
I
C
=500mA, I
B
=50mA
I
C
=500mA, I
B
=50mA
V
CE
=20V, I
C
=20mA, f=100MHz
V
CB
=10V, I
E
=0, f=1MHz
300
8
35
100
Min.
60
30
5
0.01
10
300
1
2
V
V
MHz
pF
Max.
Units
V
V
V
µA
nA
* Pulse Test: Pulse Width≤300µs, Duty Cycle≤2%
©2004 Fairchild Semiconductor Corporation
Rev. A, November 2004
PN2222
Package Dimensions
TO-92
4.58
–0.15
+0.25
0.46
14.47
±0.40
±0.10
4.58
±0.20
1.27TYP
[1.27
±0.20
]
3.60
±0.20
1.27TYP
[1.27
±0.20
]
0.38
–0.05
+0.10
3.86MAX
1.02
±0.10
0.38
–0.05
+0.10
(R2.29)
(0.25)
Dimensions in Millimeters
©2002 Fairchild Semiconductor Corporation
Rev. A, November 2004
TRADEMARKS
The following are registered and unregistered trademarks Fairchild Semiconductor owns or is authorized to use and is not
intended to be an exhaustive list of all such trademarks.
A
CEx™
ActiveArray™
Bottomless™
CoolFET™
CROSSVOLT™
DOME™
EcoSPARK™
E
2
CMOS™
EnSigna™
FACT™
FACT Quiet Series™
Across the board. Around the world.™
The Power Franchise
®
Programmable Active Droop™
FAST
®
FASTr™
FPS™
FRFET™
GlobalOptoisolator™
GTO™
HiSeC™
I
2
C™
i-Lo™
ImpliedDisconnect™
ISOPLANAR™
LittleFET™
MICROCOUPLER™
MicroFET™
MicroPak™
MICROWIRE™
MSX™
MSXPro™
OCX™
OCXPro™
OPTOLOGIC
®
OPTOPLANAR™
PACMAN™
POP™
Power247™
PowerEdge™
PowerSaver™
PowerTrench
®
QFET
®
QS™
QT Optoelectronics™
Quiet Series™
RapidConfigure™
RapidConnect™
µSerDes™
SILENT SWITCHER
®
SMART START™
SPM™
Stealth™
SuperFET™
SuperSOT™-3
SuperSOT™-6
SuperSOT™-8
SyncFET™
TinyLogic
®
TINYOPTO™
TruTranslation™
UHC™
UltraFET
®
VCX™
DISCLAIMER
FAIRCHILD SEMICONDUCTOR RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY
PRODUCTS HEREIN TO IMPROVE RELIABILITY, FUNCTION OR DESIGN. FAIRCHILD DOES NOT ASSUME ANY
LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED HEREIN;
NEITHER DOES IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS.
LIFE SUPPORT POLICY
FAIRCHILD’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT
DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF FAIRCHILD SEMICONDUCTOR
CORPORATION.
As used herein:
1. Life support devices or systems are devices or systems
2. A critical component is any component of a life support
which, (a) are intended for surgical implant into the body,
device or system whose failure to perform can be
or (b) support or sustain life, or (c) whose failure to perform
reasonably expected to cause the failure of the life support
when properly used in accordance with instructions for use
device or system, or to affect its safety or effectiveness.
provided in the labeling, can be reasonably expected to
result in significant injury to the user.
PRODUCT STATUS DEFINITIONS
Definition of Terms
Datasheet Identification
Advance Information
Product Status
Formative or In
Design
First Production
Definition
This datasheet contains the design specifications for
product development. Specifications may change in
any manner without notice.
This datasheet contains preliminary data, and
supplementary data will be published at a later date.
Fairchild Semiconductor reserves the right to make
changes at any time without notice in order to improve
design.
This datasheet contains final specifications. Fairchild
Semiconductor reserves the right to make changes at
any time without notice in order to improve design.
This datasheet contains specifications on a product
that has been discontinued by Fairchild semiconductor.
The datasheet is printed for reference information only.
Preliminary
No Identification Needed
Full Production
Obsolete
Not In Production
©2004 Fairchild Semiconductor Corporation
Rev. I13
Careers
Go
DATASHEETS, SAMPLES, BUY
TECHNICAL INFORMATION
APPLICATIONS
DESIGN CENTER
SUPPORT
COMPANY
INVESTORS
|
Sitema
MY FA
Home >> Find products >>
NPN General Purpose Amplifier
Contents
•Features
•Product
status/pricing/packaging
•Order
Samples
•Models
Features
General Purpose Transistor
back to top
This page
Print version
Product status/pricing/packaging
Product
PN2222BU
Product status
Full Production
Pb-free Status
Pricing*
$0.025
Package type
TO-92
Leads
3
e-mail this datasheet
PN2222
Related Links
Request samples
How to order products
•Application
notes
•Qualification
Support
Datasheet
Download this
datasheet
Product Change Notices
(PCNs)
Support
Sales support
Quality and reliability
Design center
Packing method
BULK
Package Marking Convention**
Line 1: PN Line 2: 2222 Line 3: -&3
PN2222TA
Full Production
$0.026
TO-92
3
AMMO
Line 1: PN Line 2: 2222 Line 3: -&3
PN2222TAR
Full Production
$0.026
TO-92
3
AMMO
Line 1: PN Line 2: 2222 Line 3: -&3
PN2222TF
Full Production
$0.026
TO-92
3
TAPE REEL
Line 1: PN Line 2: 2222 Line 3: -&3
