Z0840008VSC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> Z0840008VSC

Z0840008VSC: Description8-BIT, 8MHz, MICROPROCESSOR, PQCC44, CC-44; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，36 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

Z0840008VSC Overview

8-BIT, 8MHz, MICROPROCESSOR, PQCC44, CC-44

Z0840008VSC Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Maker	Rochester Electronics
Parts packaging code	QFN
package instruction	CC-44
Contacts	44
Reach Compliance Code	unknow
Other features	DRAM MEMORY REFRESH COUNTER
Address bus width	16
bit size	8
boundary scan	NO
maximum clock frequency	8 MHz
External data bus width	8
Format	FIXED POINT
Integrated cache	NO
JESD-30 code	S-PQCC-J44
JESD-609 code	e0
length	16.5862 mm
low power mode	NO
Humidity sensitivity level	NOT SPECIFIED
Number of terminals	44
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	240
Certification status	COMMERCIAL
Maximum seat height	4.57 mm
speed	8 MHz
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	YES
technology	NMOS
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	16.5862 mm
uPs/uCs/peripheral integrated circuit type	MICROPROCESSOR

Preview
