R25XT-68J135 Overview

Fixed Resistor, Carbon Film, 0.33W, 1300000ohm, 300V, 5% +/-Tol, 700ppm/Cel, Through Hole Mount, AXIAL LEADED

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
package instruction	AXIAL LEADED
Reach Compliance Code	compli
ECCN code	EAR99
Other features	PRECISION
structure	Nonflammable
Lead diameter	0.6 mm
Lead length	30 mm
Manufacturer's serial number	R25X
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package diameter	2.4 mm
Package length	7 mm
Package shape	TUBULAR PACKAGE
Package form	Axial
method of packing	TR
Rated power dissipation(P)	0.33 W
Rated temperature	70 °C
resistance	1300000 Ω
Resistor type	FIXED RESISTOR
series	R25X
surface mount	NO
technology	CARBON FILM
Temperature Coefficient	700 ppm/°C
Terminal shape	WIRE
Tolerance	5%
Operating Voltage	300 V

Resistors

Carbon film resistors

R25X (6.3

φ

2.4 size: 1 / 3W)

ROHM resistors are produced using an integrated production system for parts and materials, and state of the art technolo-

gy to ensure high precision productivity, and quality.

ROHM resistors are ISO-9001 certified.

The design and specifications are subject to change without prior notice. Before ordering or use, please cheak the techni-

cal specification sheets.

F

Features

1) All ceramic rods are made from the same material to

yield consistent quality.

2) Unique production methods provide outstanding me-

chanical strength characteristics.

3) Superb accuracy of axial taping for excellent high-

speed automatic insertion performance.

4) Though miniaturized, the R25X retains the high pulse

resistance of its predecessor chips.

5) Soft copper wire with solder plating offers superior

solderability.

6) Both insulator coating and its color codes are highly re-

sistant to solvents, and steam cleaning is no problem.

7) Highly nonflammable insulation coating (UL94V-0).

1
