F-211-1
TM
ACP-22 SERIES
ACP–22–01–G–00.25–T–S–P–2
ACP–22–03–G–00.25–S–S–P–3
IP68 SEALED 22mm CABLE ASSEMBLY
SPECIFICATIONS
Mates with:
ACR-22
Tested to IP68
for dust & water
For complete specifications see
www.samtec.com?ACP-22
Insulator Material:
CURRENT RATING
Thermoplastic
CCC per
Terminal Material:
LEAD
PINS
PIN
Brass
STYLE POWERED
(70°C
Contact Material:
ambient)
Brass/BeCu
Housing:
–01
30
2.0A
–P & –O: Thermoplastic
–02
20
2.3A
–M: Zinc Alloy
–03
8
8.3A
Cable Jacket:
TPU
4
RoHS Compliant:
(plus 16
Yes
–05
signal pins
2.8A
powered
@ 1.4A)
For general reference only.
See www.samtec.com?ACP-22
for complete test data or contact
AccliMate@samtec.com for
AccliMate
applications requiring higher
current carrying capacity.
Signal, power, RF
or combination
signal/power, signal/RF
ALSO
AVAILABLE
• Field Termination Kit (ACPK)
• For complete specifications
on field termination kit see
www.samtec.com?ACP-22
• Dust Caps:
DCA-ACP-22-M-X (Metal)
DCA-ACP-22-P-X (Plastic)
• Visit www.samtec.com for
a complete list of sealed
systems
Call Samtec.
*Contact
AccliMate@samtec.com for
other styles and options.
ACP
22
–01
LEAD
STYLE
PLATING
–05
= 1,5mm DIA (4)
terminals or sockets
(16 AWG)
+ 1,0mm DIA (16)
terminals or sockets
(24 AWG)
= 1,0mm DIA (30)
terminals or sockets
(24 AWG)
–G
= 10µ" (0,25µm) Gold over
50µ" (1,27µm) Ni on contact
–02
(1,0) .040
DIA (30)
–H
= 30µ" (0,76µm) Gold over
50µ" (1,27µm) Ni on contact
(1,0) .040
DIA (16)
= 1,0mm DIA (20)
terminals or sockets
(24 AWG)
–06
= 1,0mm DIA (16)
terminals or sockets
(24 AWG)
+ RF (4)
terminals or sockets
(RG 316)
–03
= 1,5mm DIA (8)
terminals or sockets
(16 AWG)
–04
= RF (8)
terminals or sockets
(RG 316)
–01
(1,0) .040
DIA (20)
RF (8)
(1,5) .060
DIA (8)
(1,0) .040
DIA (16)
RF (4)
–06
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(1,5) .060
DIA (4)
–02
–03
–04
–05
WWW.SAMTEC.COM
ACP–22–02–H–00.25–T–S–M–1
ACP–22–01–H–00.25–T–S–M–4
ACP–22–02–G–00.25–S–T–O–2
Field
termination
kit option
Choice of
terminals or sockets
Choice of
plastic, metal or
overmolded plastic
LENGTH
END 1
OPTION
END 2
OPTION
HOUSING
MATERIAL
KEYING
OPTIONS
–“XX.XX”
= Length in meters
(00.25m min. to 50m max.)
Contact Samtec for
other lengths
–T
= Terminal
–S
= Socket
–T
= Terminal
–S
= Socket
–BC
= Blunt Cut
Overall Length (XX.XX) ± 2%
–P
= Plastic
–M
= Metal
Overmolded
–O
= Plastic
–1
= Orange
–2
= Green
–3
= Blue
–4
= Yellow
(19,50)
.768
(32,50)
1.280
–P or –M
HOUSING
–O
HOUSING
KEYING OPTIONS
315°
225°
135°
45°
–1
–2
–3
–4
WWW.SAMTEC.COM
