REVISION V
DO NOT
SCALE FROM
THIS PRINT
(No OF POS x .156[.3.96]) .010[0.25]
((NO OF POS -1) x .156 [3.96])
.005 [.13]
JW-XX-XX-XX-X-XXX-XXX-XX-X
No OF POSITIONS
-02 THRU -24
LEAD STYLE
-04: T-1S8-05-X
-05: T-1S8-05-X
PLATING SPECIFICATION
-T: MATTE TIN CONTACT AND TAIL
-TM: MATTE TIN CONTACT AND TAIL
.250 6.35 REF
OPTION
-P: PICK & PLACE PAD
(USE PPP-47, SEE FIG. 2, SHEET 2)
(-VS ONLY, 3 POSITION MIN,
.275[6.99] MIN POST HEIGHT)
OPTION
-VS: VERTICAL SURFACE MOUNT
POST HEIGHT
-XXX: SPECIFY POST HEIGHT
. 000 MIN (SEE NOTE 3)
SPACE OPTION
-XXX: SPECIFY BOARD SPACING
ROW SPECIFICATION
-S: SINGLE (USE HFWJ-24-156)
.078 1.97
.125 3.18
-S: SINGLE
2 MAX SWAY
(EITHER DIRECTION)
HFWJ-24-156
-S IN-PROCESS
POST HEIGHT
-VS IN-PROCESS
V
V
24
01
1.350 34.29
REF
SPACE OPTION
POST HEIGHT
V
SPACE OPTION
-.100
V
-VS: VERTICAL SURFACE MOUNT
C
.265 6.73 MIN
(SEE NOTE 3)
.045 1.14 SQ. REF
POST HEIGHT
-XXX .008[0.20]
(.000 MIN)
C
.125 3.18 REF
SPACE OPTION
-XXX .008[0.20]
(1.080[27.43] MAX,
.250[6.35] MIN)
1.250 [31.75]
MAX
SPACE OPTION
-XXX .008[0.20]
(1.150[29.21] MAX,
.350[8.89] MIN)
.225 5.72
C
C
90°
- 0°
.008[0.20]
+4°
T-1S8-05-T
.09 2.29
SEE NOTES 3 & 4
SEE NOTES 3 & 5
.31 7.87
NOTES:
1. HEIGHT VARIATION BETWEEN ANY TWO PINS SHALL BE .010[0.25] MAX.
2. MAXIMUM PIN ROTATION IN BODY: 2 .
3. TAIL TO BE SHEARED TO .265[6.73] MIN. A SECOND SHEAR STEP WILL
BE NEEDED AFTER FORMING TO ACHIEVE THE TAIL TO TAIL DIM.
4. MAXIMUM BURR ALLOWED: .004[0.10].
5. MAXIMUM BURR ALLOWED: .0015[0.038].
6. THROUGH HOLE TO BE BULK PACKAGED.
7. VERTICAL SURFACE MOUNT (-VS) TO BE PACKAGED AS FOLLOWS:
POSITIONS -04 THRU -24 ARE TO BE PACKAGED IN TUBES (SEE TABLE 1, SHEET 2);
POSITIONS -02 AND -03 ARE TO BE LAYER PACKAGED.
8. MIN PUSHOUT FORCE TO BE 3 LBS.
9. MAX CUT FLASH TO BE .020[0.51].
10.
C
REPRESENTS A CRITICAL DIMENSION.
-S: SINGLE
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
-VS: VERTICAL SURFACE MOUNT
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 1.25:1
INSULATOR: LCP, COLOR: NATURAL
TERMINAL: PHOSPHOR BRONZE
MAX BOW ALLOWED: .002[0.05] IN/IN
F:\DWG\MISC\Mktg\JW-XX-XX-XX-X-XXX-XXX-XX-X-MKT.SLDDRW
.156[3.96] POWER STACKER ASSEMBLY
BY:
KEVIN B
JW-XX-XX-XX-X-XXX-XXX-XX-X
06/12/2002
SHEET
1
OF
2
REVISION V
FIG 2
-P: PICK & PLACE PAD OPTION
(-VS ONLY, 3 POS. MIN)
NOTE:
"R" = No OF POS x .156[3.96] REF
"S" = {("R" - .450[11.43]) / 2} .020[12.90]
"G" = POST HEIGHT (.275[6.99] MIN) + .050[1.27] REF
"R"
"S"
"G"
.300 7.62 REF
.450 11.43 REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
.156[3.96] POWER STACKER ASSEMBLY
F:\DWG\MISC\Mktg\JW-XX-XX-XX-X-XXX-XXX-XX-X-MKT.SLDDRW
BY:
KEVIN B
JW-XX-XX-XX-X-XXX-XXX-XX-X
06/12/2002
SHEET
2
OF
2
