F-213-1
Choice of
PVC or
Teflon
®
cable
™
(2,00 mm) .0787"
S2SD, S2SDT, ISD2, CC81 SERIES
Optional
retention
latching
S2SD–30–24–L–05.00–SR
TIGER EYE DISCRETE WIRE SOCKET CABLE
Mates with:
T2M
™
TYPE
PINS PER
ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLED
LENGTH
END
OPTION
END 2
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?S2SD
or www.samtec.com?S2SDT
Insulator Material:
Black LCP
Contact Material:
FILE NO. E111534
BeCu
Plating:
Au over 50µ" (1,27 µm) Ni
Wire:
24, 26, 28 or 30 AWG
Operating Temp Range:
-35°C to +105°C (PVC)
-55°C to +125°C (*Teflon
®
)
Voltage Rating:
250 VAC
RoHS Compliant:
Yes
CURRENT RATING
(PER CONTACT)
AMBIENT
S2SD/T2M
TEMP
20°C
40°C
60°C
95°C
4.9A
4.4A
3.8A
2.6A
S2SD
= Double Row
PVC Cable
S2SDT
= Double Row
*Teflon
®
Cable
(24, 28, 30
Gauge only)
–05,
–07,
–10,
–15,
–20,
–25,
–30
(Call Samtec
for other
sizes)
–24
–24C
= Color
Coded
Cable
(S2SD
only)
–L
= 10µ"
(0,25 µm)
Gold on
contact
–“XX.XX”
= Wire
Length
in Inches
(69,85 mm)
02.75" min.
No. of positions x
(2,00) .0787 + (3,50) .138
02
–S
= Single End
(Only available
with –D,
–DR & –DS)
™
–26
–28
–30
(5,15)
.203
(2,64)
.104
(7,52)
.296
(2,00)
.0787
01
(2,11) .083
(4,42)
.174
(11,38)
.448
= Notch up,
= Double End
straight
(Pin 1 to Pin N-1)
Specify "S" for
single ended
and "D" for
double ended. = Notch down,
straight
(Pin 1 to Pin 2)
= Retention
Latch
(-SR mates
= Notch up,
with T2M-WT)
crossed
(Pin 1 to Pin N)
–D
–NUS
–NDS
–(X)R
–NUX
–(X)S
Assembly
Length
± (3,18)
.125
= Screw Down
(10 positions
minimum)
(mates with
T2M-DS)
–NDX
= Notch down,
crossed
(Pin 1 to Pin 1)
6 POSITIONS (2x3)
24 AWG POWERED
(1,60)
.063
ALSO AVAILABLE
Bodies, contacts and
assembly tooling.
Call Samtec.
• Tiger Eye™ contacts
• Retention latches
–SR
–D–NUS
APPLICATION
–24C CABLE
COLOR CODING
PIN
1
2
3
4
5
6
7
8
9
10
ETC
™
TYPE
POSITIONS
PER ROW
ROW
OPTION
LATCH
OPTION
TYPE
WIRE
GAUGE
01
L
COLOR
BROWN
RED
ORANGE
YELLOW
GREEN
VIOLET
GRAY
WHITE
BLACK
BLUE
REPEAT
®
ISD2
= Body,
Loose
–05,
–07, –10,
–15, –20,
–25, –30
(Call Samtec
for other sizes)
–D
= Double
Row
–M
= Metal
Retention
Latch
CC81L
= Contact, Loose
–2426
= 24 to 26 AWG
–L
= 10µ"
(0,25 µm)
Gold on
contact
–S
= Screw
Down
CC81R
= Contact,
Full Reel
(17,000 Parts
per Reel)
–2830
= 28 to 30 AWG
*DuPont Teflon is a
registered trademark of the
E.I. du Pont de Nemours
and Company or its affiliates.
Note:
For wiring option
information refer to drawing
on web.
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
(2,07) .081
(2,03)
.080
(2,64)
.104
(2,00)
.079
DIA
(3,68)
.145
(12,35)
.486
(0,38)
.014
(1,78)
.070
(1,27)
.050
DIA
(6,00)
.236
(3,17)
.125
–M
–S
