Series 193 SMT DIP

Side Actuated,

Surface Mount

DIP Switches

Features

Optimized Mechanical Features

• Coplanarity: 0.1mm/.004" maximum

• Enclosed actuators shield contacts from foreign

particles throughout life of switch

• Gull-wing terminal configuration

• Compatible with SMT assembly including IR and

Vapor-phase (up to 260°C)

• SPST configuration,2 through 10 positions

• Contact wiping action on make and break

• Integral terminal and contact locked into high temperature

plastic base

• Lock-over-center design provides positive detent action

• Optimized, active contact design incorporating

dimple-to-flat surface wiping interface with high

contact force

• Gold plated contacts for long-term contact corrosion

resistance

• Tin plated terminals for better solderability

• All UL 94V-0 plastic used

• RoHS compliant

Optimized Contact System

Materials

Electrical and Mechanical Specifications

Switch Function

SPST-2 through 10 positions

Switch Contact Resistance

50 milliohms maximum initial

100 milliohms maximum at end of life

Insulation Resistance

1,000 megohms minimum between insulated terminals

Dielectric Strength

500 VAC for 1 minute between adjacent

switches

Nonswitching Rating

100 mA or 50 VDC maximum

Switch Capacitance

5.0 pF maximum between adjacent closed switches

Operating Temperature

–40°C to +85°C

Actuation Life

7,000 cycles switching 50 mA @ 24 VDC

Coplanarity

Coplanarity of 0.1mm / .004" max

Allowable Solder Time

Up to 60 seconds at 260°C

Vibration

Per MIL-STD-202F, method 204D, condition B

(.06" or 15G’S between 10 HZ to 2K HZ) with no

contact inconsistencies greater than 1 microsecond

Shock

Per MIL-STD-202F, method 213B, condition A

(50G’S) with no contact inconsistencies greater

than 1 microsecond

Sealing

Bottom epoxy seal standard

Marking

Special side or top marking available-consult CTS

Packaging

Standard : Anti-static tube packaging

Optional : Tape and reel packaging

1-2

CTS Electrocomponents

05/05/08

www.ctscorp.com
