Icu 100 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
Icu 70 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
Icu 65 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
Icu 30 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
Icu 22 kA at 525 V AC 50/60 Hz conforming to IEC 60947-2
Icu 10 kA at 660...690 V AC 50/60 Hz conforming to IEC 60947-2
690 V AC 50/60 Hz conforming to IEC 60947-2
100 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
70 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-2
65 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
30 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2
22 kA at 525 V AC 50/60 Hz conforming to IEC 60947-2
2.5 kA at 660...690 V AC 50/60 Hz conforming to IEC 60947-2
8 kV conforming to IEC 60947-2
1
[Ue] rated operational voltage
[Ics] rated service breaking capacity
[Uimp] rated impulse withstand voltage
Aug 17, 2019
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
[Ui] rated insulation voltage
Trip unit technology
Trip unit name
Trip unit protection functions
Trip unit rating
Protection type
Long time pick-up adjustment range
Short-time pick-up adjustment type Isd
Short-time delay adjustment type
Magnetic hold current
Magnetic tripping current
Suitability for isolation
Utilisation category
9 mm pitches
Connection pitch
Connections - terminals
Thread type
Thickness
Tightening torque
Local signalling
Number of slots
800 V conforming to IEC 60947-2
Thermal-magnetic
TM-D
LI
25 A at 40 °C
Short-circuit protection (magnetic)
Overload protection (thermal)
0.7...1 x In
Fixed
Fixed
480 A
720 A
Yes conforming to IEC 60947-2
Category A
12 module
35 mm with spreaders
27 mm without spreaders
compression lug/busbar
M6
8 mm
5 N.m for 2.5…10 mm²
9 N.m for 16…95 mm²
Presence of auxiliary contacts: flag (green)
1 slot(s) for auxiliary switch OF
1 slot(s) for alarm switch SD
1 slot(s) for voltage release MN or MX
20 mm
Power wire stripping length
Environment
Quality labels
Standards
Product certifications
CE
EN/IEC 60947
CCC
EAC
Marine
Grey (RAL 7016)
Front cover: IP40 conforming to IEC 60529
IK07 conforming to IEC 62262
3 conforming to IEC 60947-1
-25…70 °C
-40…85 °C
2000 m without derating
5000 m with derating
20000 cycles conforming to IEC 947-1 Annex K ed 5.2 In
10000 cycles conforming to IEC 947-1 Annex F ed 5.2 for In at 440 V
137 mm
108 mm
80 mm
1.42 kg
Set of 1
Colour
IP degree of protection
IK degree of protection
Pollution degree
Ambient air temperature for operation
Ambient air temperature for storage
Operating altitude
Mechanical durability
Electrical durability
Height
Width
Depth
Net weight
Quantity per set
Offer Sustainability
Sustainable offer status
REACh Regulation
EU RoHS Directive
Green Premium product
REACh Declaration
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
2
Mercury free
RoHS exemption information
China RoHS Regulation
Environmental Disclosure
Circularity Profile
WEEE
Yes
Yes
Download RoHS China Declaration
Product out of China RoHS scope. Substance declaration for your information
Product Environmental Profile
No need of specific recycling operations
The product must be disposed on European Union markets following specific waste collection and
