PC714V0YSZX Overview

Transistor Output Optocoupler, 1-Element, 5000V Isolation, DIP-6

PC714V0YSZX Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	SHARP
package instruction	DIP-6
Reach Compliance Code	unknow
Other features	UL RECOGNIZED, VDE APPROVED
Coll-Emtr Bkdn Voltage-Mi	80 V
Configuration	SINGLE
Nominal current transfer ratio	50%
Maximum dark power	100 nA
Maximum forward current	0.05 A
Maximum insulation voltage	5000 V
JESD-609 code	e0
Number of components	1
Maximum operating temperature	100 °C
Minimum operating temperature	-25 °C
Optoelectronic device types	TRANSISTOR OUTPUT OPTOCOUPLER
Terminal surface	Tin/Lead (Sn/Pb)

Preview

Download Datasheet

View All

PC714VxNSZX Series

PC714VxNSZX

Series

DIP 6 pin General Purpose

Photocoupler

■

Description

PC714VxNSZX Series

contains an IRED optically

coupled to a phototransistor.

It is packaged in a 6 pin DIP.

Input-output isolation voltage(rms) is 5.0kV.

Collector-emitter voltage is 80V

(*)

and CTR is 50%

to 600% at input current of 5mA.

■

Agency approvals/Compliance

1. Recognized by UL1577 (Double protection isolation),

file No. E64380 (as model No.

PC714V)

2. Approved by TÜV (VDE0884) (as an option) file No.

R-9151576 (as model No.

PC714V)

3. Package resin : UL flammability grade (94V-0)

■

Features

1. 6 pin DIP package

2. Double transfer mold package (Ideal for Flow Solder-

ing)

3. High collector-emitter voltage (V

CEO

:80V

(*)

)

4. High isolation voltage between input and output

iso(rms)

: 5.0kV)

(*) Up to Date code "P7" (July 2002) V

CEO

: 35V.

■

Applications

1. Home appliances

2. Programmable controllers

3. Personal computer peripherals

Notice The content of data sheet is subject to change without prior notice.

In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP

devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.

Sheet No.: D2-A04101EN

Date Nov. 28. 2003
