Data sheet
3SB3202-0AA31
22MM PLASTIC ROUND COMPLETE UNIT COMBINATION:
PUSHBUTTON WITH FLAT BUTTON SCREW TERMINAL, 1NO
WITH HOLDER YELLOW !!! Phased-out product !!! SIRIUS ACT
3SU1 is successor Preferred successor type is >>3SU1100-0AB30-
1BA0<<
Complete unit round
Design of the product
Enclosure
Shape of the enclosure front
Material of the enclosure
Number of command points
round
plastic
1
Actuator
Design of the operating mechanism
Manner of function of the actuating element
Product extension optional Light source
Color
● of the actuating element
Material of the actuating element
Shape of the actuating element
Type of unlocking device
Number of switching positions
yellow
plastic
Flat pushbutton
without
2
Pushbutton
momentary contact type
No
Front ring
Product component front ring
Design of the front ring
Material of the front ring
Color of the front ring
Yes
Standard
plastic
black
Holder
Material of the holder
Plastic
Contact block/ lampholder
Number of lampholders
Number of switching elements
0
1
General technical data
Product function
● positive opening
● EMERGENCY STOP function
Product component
● Light source
Type of voltage
No
No
No
3SB3202-0AA31
Page 1/5
11/20/2019
Subject to change without notice
© Copyright Siemens
● of the operating voltage
Protection class IP
Vibration resistance
● acc. to IEC 60068-2-6
Operating frequency maximum
Mechanical service life (switching cycles)
● typical
Reference code acc. to DIN 40719 extended
according to IEC 204-2 acc. to IEC 750
Reference code acc. to DIN EN 81346-2
Operating voltage
● rated value
AC/DC
IP66
20 ... 200 Hz: 5g
1 000 1/h
10 000 000
S
S
5 ... 400 V
Auxiliary circuit
Number of NC contacts for auxiliary contacts
Number of NO contacts for auxiliary contacts
Number of CO contacts
● for auxiliary contacts
Operating current at AC-12
● at 48 V rated value
● at 110 V rated value
Operating current at AC-15
● at 48 V rated value
● at 110 V rated value
Operating current at DC-12
● at 48 V rated value
● at 110 V rated value
Operating current at DC-13
● at 48 V rated value
● at 110 V rated value
● at 230 V rated value
1.5 A
0.7 A
0.3 A
5 A
2.5 A
6 A
6 A
10 A
10 A
0
0
1
Connections/ Terminals
Type of electrical connection
Tightening torque of the screws in the bracket
screw-type terminals
1 ... 1.2 N·m
Ambient conditions
Ambient temperature
● during operation
● during storage
Environmental category during operation acc. to IEC
60721
-25 ... +70 °C
-40 ... +80 °C
3K6
Installation/ mounting/ dimensions
Mounting type
front mounting
3SB3202-0AA31
Page 2/5
11/20/2019
Subject to change without notice
© Copyright Siemens
Shape of the installation opening
Mounting diameter
Mounting height
Installation width
Installation depth
round
22 mm
8 mm
28.5 mm
49 mm
Accessories
Product component holder for 3 switching elements
No
Certificates/ approvals
General Product Approval
Declaration of Conformity
Miscellaneous
Marine / Shipping
other
Miscellaneous
Confirmation
other
Environmental Con-
firmations
Railway
Special Test Certi-
ficate
Further information
Information- and Downloadcenter (Catalogs, Brochures,…)
www.siemens.com/sirius/catalogs
Industry Mall (Online ordering system)
https://mall.industry.siemens.com/mall/en/en/Catalog/product?mlfb=3SB3202-0AA31
Cax online generator
http://support.automation.siemens.com/WW/CAXorder/default.aspx?lang=en&mlfb=3SB3202-0AA31
Service&Support (Manuals, Certificates, Characteristics, FAQs,...)
https://support.industry.siemens.com/cs/ww/en/ps/3SB3202-0AA31
Image database (product images, 2D dimension drawings, 3D models, device circuit diagrams, EPLAN macros, ...)
http://www.automation.siemens.com/bilddb/cax_de.aspx?mlfb=3SB3202-0AA31&lang=en
3SB3202-0AA31
Page 3/5
11/20/2019
Subject to change without notice
© Copyright Siemens
3SB3202-0AA31
Page 4/5
11/20/2019
Subject to change without notice
© Copyright Siemens
last modified:
11/09/2019
3SB3202-0AA31
Page 5/5
11/20/2019
Subject to change without notice
© Copyright Siemens
