DC-DC Converter UNIT
1R Serie
( 1W SINGLE OUTPUTS WITH REGULATION )
FEATURES
1000VDC ISOLATION
HIGH EFFICIENCY
INTERNAL FILTERING
LOW COST
NO EXTERNAL COMPONENTS
REQUIRED
UP TO 1W REGULATED OUTPUT
POWER
SINGLE IN LINE PACKAGE
100% BURNED IN
LOW NOISE
MTBF > 800,000 HOURS
OUTPUT SPECIFICATIONS
Voltage Set point Accuracy
Temperature Coefficient
Ripple & Noise (20MHz BW)
Line Regulation
1
Load Regulation
2
Short Circuit Protection
Short Circuit Restart
INPUT SPECIFICATIONS
+/-2% max Input Voltage Range
+/-0.03%/
O
C Input Filter
100mVp-p max
+/-0.5% max
+/-0.5% max
+/-10% max
Capacitor Type
GENERAL SPECIFICATIONS
60% min
1000 VDC min
9
10 ohms min
50 KHz min
80pF max
800,000 Hours
7.0g Typ
Non-Conductive Plastic
31.8mm*8.6mm*14.5mm
Current Limit Protection Efficiency
Automatic Isolation Voltage
3
Isolation Resistance
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
Storage Temperature
Cooling
-25
O
C to +71
O
C Switching Frequency
-55
O
C to +125
O
C Isolation Capacitance
Free-Air Convection MTBF
Weight
ALL SPECIFICATIONS TYPICAL AT NOMINAL LINE,
FULL LOAD , AND 25
O
C
UNLESS OTHERWISE
NOTED.
Case Material
Case Size
1
2
3
High Line to Low Line.
Load Regulation is for output load current change from 10% to 100%.
For 60 seconds
www.Power-Systems.de
Page: 1 / 5
Version: 4-Oct-02
DC-DC Converter UNIT
1R Serie
( 1W SINGLE OUTPUTS WITH REGULATION )
SELECTION GUIDE
1W OUTPUT
MODEL
NUMBER
INPUT
(VDC)
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
4.5-5.5
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
10.8-13.2
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
21.6-26.4
OUTPUT
(VDC)
5
9
12
15
+/-5
+/-12
+/-15
5
9
12
15
+/-5
+/-12
+/-15
5
9
12
15
+/-5
+/-12
+/-15
OUTPUT
(mA)
200
111
84
67
+/-100
+/-42
+/-34
200
111
84
67
+/-100
+/-42
+/-34
200
111
84
67
+/-100
+/-42
+/-34
INPUT
CURRENT(mA)
FULL
LOAD
NO
LOAD
23
22
22
21
23
22
21
15
15
15
15
15
15
15
7
6
6
6
7
6
6
62
60
62
62
62
62
62
67
62
64
63
67
64
63
68
65
70
70
68
70
70
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
VOLTAGE VOLTAGE CURRENT
EFF
(%)
ISOLATION
(VDC)
1RS-0505
1RS-0509
1RS-0512
1RS-0515
1RD-0505
1RD-0512
1RD-0515
1RS-1205
1RS-1209
1RS-1212
1RS-1215
1RD-1205
1RD-1212
1RD-1215
1RS-2405
1RS-2409
1RS-2412
1RS-2415
1RD-2405
1RD-2412
1RD-2415
322
333
322
322
322
322
322
124
134
130
132
124
130
132
61
64
60
60
61
60
60
Note: Other input to output voltages may be available. Please contact factory.
www.Power-Systems.de
Page: 2 / 5
Version: 4-Oct-02
DC-DC Converter UNIT
1R Serie
( 1W SINGLE OUTPUTS WITH REGULATION )
SIMPLIFIED SCHEMATIC
SINGLE OUTPUT
+Vin
OSCILLATOR
DRIVER
REGULATOR
DUAL OUTPUT
+Vout
+Vin
OSCILLATOR
DRIVER
REGULATOR
+Vout
Com.
-Vout
-Vin
-Vout
-Vin
REGULATOR
MECHANICAL DIMENSIONS &
RECOMMENDED FOOTPRINT DETAILS
PIN
1
2
3
9
10
11
12
SINGLE
+Vin
NC
NC
NC
-Vout
+Vout
-Vin
DUAL
+Vin
-Vout
NC
NC
Common
+Vout
-Vin
www.Power-Systems.de
Page: 3 / 5
Version: 4-Oct-02
DC-DC Converter UNIT
1R Serie
( 1W SINGLE OUTPUTS WITH REGULATION )
TYPICAL APPLICATIONS
SINGLE OUTPUT
INPUT
+Vin
+Vout
DUAL OUTPUT
INPUT
+Vin
+Vout
OUTPUT
OUTPUT
LOAD1
DC-DC
CONVERTER
-Vin
-Vout
LOAD
DC-DC
CONVERTER
-Vin
Common
LOAD2
-Vout
TYPICAL PERFORMANCE CUREVES
Specifications typical at ta=25
O
C,nominal input voltage , rated output current unless otherwise specified.
OUTPUT LOAD vs EFFICIENCY
100%
EFFICIENCY(%)
80%
60%
40%
20%
0%
0%
OUTPUT VOLTAGE
CHANGE(%)
80%
100%
OUTPUT LOAD vs OUTPUT VOLTAGE
10%
5%
0%
-5%
-10%
0%
SAFE
OPERATING
AREA
20%
40%
60%
20%
40%
60%
80%
100%
OUTPUT LOAD(%)
OUTPUT LOAD(%)
TEMPERATURE DERATING
1.2
OUTPUT POWER(W)
0.9
0.6
0.3
0.0
-25
0
25
50
70
100
TA(degree C)
EFFICIENCY(%)
100%
80%
60%
40%
20%
INPUT VOLTAGE vs EFFICIENCY
0%
-10
-5
Nom
5
10
INPUT VOLTAGE(%)
www.Power-Systems.de
Page: 4 / 5
Version: 4-Oct-02
DC-DC Converter UNIT
1R Serie
( 1W SINGLE OUTPUTS WITH REGULATION )
1R SERIES APPLICATION NOTES:
EXTERNAL CAPACITANCE REQUIREMENTS:
No external capacitance is required for operation of the 1R series.
To meet the reflected ripple requirements of the converter, an input impedance of less than 0.5 ohm
from DC to 100KHz is required.
External output capacitance is not required for operation, however it is recommended that 10uF
tantalum and 0.1uF ceramic capacitance be selected for reduced system noise.
Additional output capacitance may be added for increased filtering, but should not exceed 220uF.
Negative Outputs:
A negative output voltage may be obtained by connecting the +OUT to circuit ground and
connecting –OUT as the negative output.
FOR MORE INFORMATION CALL:
Power Systems – The Power Solution
74360 Ilsfeld-Auenstein ( Germany ) Dörnet 8
E-mail: Info@Power-Systems.de
Tel: + 49 / 70 62 / 67 59 – 6
Fax: + 49 / 70 62 / 67 59 -80
Home Page: www.Power-Systems.de
www.Power-Systems.de
Page: 5 / 5
Version: 4-Oct-02
