T90S5D42-18 Product Details
Powe r PC Board Re lays
Converted to EU RoHS but not ELV Compliant
(
Statement of Compliance
)
Previous 1
...
11 12
[13]
14 15
...
20 Next
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Product Highlights:
T90 Series
Contact Arrangement = 1 Form C, SPDT, 1 C/O
Contact Current Rating = 20 Amps.
Monostable Coil Magnetic System
Without Coil Suppression Diode
View all Features
|
Find Similar Products
T90S5D42-18
Active
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
T90 30 Amp Printed Circuit Board Relay
(PDF, English)
Additional Information:
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Product Line Information
Additional Product Images:
Schematic
PCB Layout
Wiring Diagram
Related Products:
Tooling
List all Documents
Product Features
(Ple ase u se the Produ ct Drawin g for all de sign activity)
Product Type Features:
Termination Type
= Through Hole
Comment = No common terminal between coil terminals (see wiring
diagram).
Electrical Characteristics:
Contact Current Rating (Amps.)
= 20
Coil Resistance (?)
= 380
Coil Power, Nominal (mW)
= 850
Actuating System
= DC
Input Voltage (VDC)
= 18
Body Related Features:
Series
= T90
Polarized = No
Contact Related Features:
Mounting Options
= PC Board
Enclosure
= Sealed
FCC Part 68 Isolation = No
Relay Type = PCB
Contact Material
= Silver Cadmium Oxide
Approx. Dimensions (L x W x H) (mm [in]) = 30.50 x 24.10 x 16.90 [1.201
x .949 x .665]
Wiring Diagram = 1 Form C
Approved Standards = UL Recognized, CSA Component Acceptance, CSA
Certified
Other:
Brand = Potter & Brumfield
Configuration Related Features:
Contact Arrangement
= 1 Form C, SPDT, 1 C/O
Coil Magnetic System
= Monostable
Coil Suppression Diode
= Without
Coil Selection Criteria
= Nominal Voltage
Coil Latching = Without
LED Indicator
= Without
Industry Standards:
RoHS/ELV Compliance
= RoHS/Not ELV Compliant
Lead Free Solder Processes
= Wave solder capable to 240C, Wave solder
capable to 260C
RoHS/ELV Compliance History = Converted to comply with RoHS not
ELV directives
Coil Insulation Classification = UL Class F
