Home > Products > Relays > Product Feature Selector > Product Details
814220292 Product Details
Communications/Signal PC Board Relays
Converted to EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Cradle N/V23154/V23162 Series
Contact Current Class = 0A to 2A Class
Contact Rated Current = .2 A
Terminal Type = Plugin, Solder
Contact Arrangement = 4 Form C (CO)
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
814220292
TE Internal Number: 814220292
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Mechanical Attachment:
Mounting Options = Screw Mount
Electrical Characteristics:
Contact Current Class = 0A to 2A Class
Contact Rated Current (A) = 0.2
Contact Limiting Continuous Current (A) = 2
Contact Limiting Making Current (A) = 0.2
Contact Limiting Breaking Current (A) = 0.2
Insulation Initial Dielectric Between Coil/Contact Class = 500V to
1000V Class
Insulation Initial Dielectric Between Open Contacts (V rms) = 500
Insulation Initial Dielectric Between Contacts and Coil (V rms) =
1000
Contact Rated Voltage (VAC) = 36
Contact Rated Voltage (VDC) = 36
Contact Switching Voltage Max. (VAC) = 36
Contact Switching Voltage Max. (VDC) = 36
Contact Limiting ShortTime Current (A) = 0.2
Coil Rated Voltage (VDC) = 12
Coil Resistance (Ω) = 220
Coil Rated Power, DC (mW) = 655
Coil Rated Power Class = 600mW to 800mW Class
Insulation Initial Insulation Resistance (MΩ) = 1000
Dimensions:
Mechanical Length Class = 25mm to 30mm Class
Length (mm [in]) = 30.00 [1.181]
Mechanical Width Class = 16mm to 20mm Class
Width (mm [in]) = 19.00 [0.748]
Mechanical Height Class = 25mm to 30mm Class
Height (mm [in]) = 30.00 [1.181]
Body Features:
Weight (g [oz]) = 25.00 [0.883]
Mount Type = Screw Mount, Socket
Contact Features:
Terminal Type = Plugin, Solder
Contact Material = Gold F
Contact Number of Poles = 4
Configuration Features:
Contact Arrangement = 4 Form C (CO)
Coil Magnetic System = Monostable, DC
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Converted to comply with RoHS
directive
Environmental:
Environmental Category of Protection = RTI
Environmental Ambient Temperature, Max. (°C [°F]) = 70 [158]
Environmental Ambient Temperature Class = 50°C to 70°C Class
Packaging Features:
Packaging Method = Box/Carton
Other:
Series = Cradle N/V23154/V23162
Brand = AMP
Additional Features = Earth Terminal, Silver Plated Terminals
