◆Low
Power Consumption: 0.8µA/ch. (TYP.)
◆Input
Voltage Range : 1.5V ~ 6.0V
◆Output
Voltage Range : 0.9V ~ 5.0V
(can be set by channel)
◆Maximum
Output Current
: 200mA (300mA Limit, TYP.)
@ V
OUT
=3.0V, V
IN
=4.0V
◆Current
Limiter Circuit Built-In
◆Ceramic
Capacitor Compatible
◆Dual
Regulator with Dual Input LDO
(XC6411P/XC6412C)
■APPLICATIONS
●MP3
players, Portable AV equipment
●Mobile
phones
●Cordless
phones,
wireless communication equipment
●Portable
games
●Cameras,
Video recorders
●PDAs
■GENERAL
DESCRIPTION
■FEATURES
Maximum Output Current
: 200mA (300mA Limit, TYP.)
@ V
OUT
=3.0V, V
IN
=4.0V
Dropout Voltage
: 320mV @ I
OUT
= 100mA
@ V
OUT
= 3.0V
Operating
Input Voltage Range
: 1.5V ~ 6.0V
Output Voltage Range
: 0.9V ~ 5.0V (100mV increments)
Highly Accurate
: Set voltage accuracy
±2%
(1.5V<V
OUT(T)<
5.0V)
Set voltage accuracy
±30mV
(0.9V<V
OUT(T)<
1.5V)
Low Power Consumption
: 0.8µA / ch.(TYP.)
Operating Temperature Range
: - 40℃~ 85℃
Low ESR Capacitor Compatible
: Ceramic capacitor
Ultra Small Packages
: SOT-25 (XC6411P)
: SOT-26 (XC6412B)
: USP-6C (XC6412C) *Preliminary
The XC6411/6412 series are highly precise, low noise, positive
voltage LDO dual regulators manufactured using CMOS
processes. The series achieves very low supply current, 0.8µA
/ ch. (TYP.) and consists of a reference voltage source, an error
amplifier, a current foldback circuit, and a phase compensation
circuit plus a driver transistor. SOT-25 package for the
XC6411P series, SOT-26 package for the XC6412B series and
USP-6C package for the XC6412C series (preliminary) make
high density mounting possible. Therefore, the series is ideal
for applications where high density mounting is required such
as in mobile equipment.
Output voltage of each regulators VR1 and VR2 is selectable in
100mV increments within a range of 0.9V to 5.0V by laser
trimming. The series is also compatible with low ESR ceramic
capacitors, which give added output stability. VR1 and VR2
are completely isolated. For this, a cross talk between each
channel, which causes a problem during load fluctuations, can
be greatly reduced, and the stabilized voltage can be supplied.
The current limiter's foldback circuit also operates as a short
protect for the output pin.
■TYPICAL
APPLICATION CIRCUIT
V
IN1
4
3
V
OUT1
1uF
(ceramic)
■TYPICAL
PERFORMANCE
CHARACTERISTICS
●Supply
Current vs. Input Voltage
VR1/VR2: 3.0V
CIN=1.0µF(ceramic),CL=0.1µF(ceramic)
XC6411
series
2
0.1uF
(ceramic)
1.4
V
IN2
5
V
OUT2
1.2
(µA)
SS
1uF
(ceramic)
1
0.1uF
(ceramic)
1.0
0.8
0.6
0.4
0.2
0.0
0
1
2
3
4
5
6
Input Voltage VIN (V)
Ta=-40℃
Ta=25℃
Ta=85℃
V
IN
1
V
OUT1
1uF
(ceramic)
2
XC6412
series
EN2
3
5
0.1uF
(ceramic)
V
OUT2
4
0.1uF
(ceramic)
Supply Current I
6
XC6411_12 ETR0320_004.doc
1
XC6411/6412
Series
■PIN
CONFIGURATION
V
IN2
5
V
IN1
4
EN2
3
NC
2
V
IN
1
V
IN1
6
V
IN2
5
EN2 4
1 V
OUT1
2 V
SS
3 V
OUT2
2
3
V
OUT2
V
SS
V
OUT1
XC6411P Series
SOT-25 (TOP VIEW)
1
4
5
6
XC6412C Series
USP-6C (BOTTOM VIEW)
*Preliminary
* The dissipation pad for the USP-6C package
should be solder-plated in recommended
mount pattern and metal masking so as to
enhance mounting strength and heat release.
If the pad needs to be connected to other pins,
it should be connected to the V
SS
pin (pin # 5).
V
OUT2
V
SS
V
OUT1
XC6412B Series
SOT-26 (TOP VIEW)
■PIN
ASSIGNMENT
XC6411P
SOT-25
1
2
3
-
4
5
-
-
PIN NUMBER
XC6412B
SOT-26
4
5
6
1
-
-
3
2
XC6412C
USP-6C
3
2
1
-
6
5
4
-
PIN NAME
V
OUT2
V
SS
V
OUT1
V
IN
V
IN1
V
IN2
EN2
NC
FUNCTION
Output 2
Ground
Output 1
Power Input
Power Input 1
Power Input 2
ON / Off Switch (ch. 2)
No Connection
* When using an SOT-26 package of the XC6412B series, please use No. 1 pin as power input of the whole IC.
■PRODUCT
CLASSIFICATION
●Ordering
Information
XC6411P①②③④⑤
XC6412B①②③④⑤
XC6412C①②③④⑤ *Preliminary
DESIGNATOR
①②③
DESCRIPTION
Output Voltage
SYMBOL
001~
DESCRIPTION
: Internally set sequential number relating output voltage of each
regulator. Regulator 1 and 2 output voltage range→0.9~5.0V
(100V increments)
: SOT-25 (XC6411P)
: SOT-26 (XC6412B)
: USP-6C (XC6412C)
: Embossed tape, standard feed
: Embossed tape, reverse feed
④
Package
M
E
⑤
Device Orientation
R
L
2
XC6411/6412
Series
■ELECTRICAL
CHARACTERISTICS (Continued)
XC6411P/6412 Series, Regulator 1 and Regulator 2 (Continued)
PARAMETER
SYMBOL
CONDITIONS
V
OUT
=V
OUT(E)
×0.95
V
OUT(T)
=0.9V
V
IN
=V
OUT(T)+
2.0V
V
OUT
=V
OUT(E)
×0.95
V
OUT(T)
=1.0V ~ 1.1V
V
IN
=V
OUT(T)+
2.0V
V
OUT
=V
OUT(E)
×0.95
V
OUT(T)
=1.2V ~ 1.3V
V
IN
=V
OUT(T)+
2.0V
V
OUT
=V
OUT(E)
×0.95
V
OUT(T)
=1.4V ~ 2.9V
V
IN
=V
OUT(T)+
2.0V
V
OUT
=V
OUT(E)
×0.95
V
OUT(T)
≧3.0V
V
IN
=V
OUT(T)+
1.0V
V
IN
=V
OUT(T)+
1.0V,
V
OUT
=0V
MIN.
100
TYP.
300
MAX.
-
Ta = 25℃
UNIT. CIRCUIT
120
300
-
mA
Current Limit
I
LIM
160
300
-
①
200
300
-
200
-
300
50
-
-
mA
①
Short Circuit Current
Ishort
NOTE: *1: V
OUT(T):
Setting output voltage
*2: V
OUT(E)
= Effective output voltage
(i.e. the output voltage when “V
OUT(T)
+ 1.0V” is provided at the V
IN
pin while maintaining a certain I
OUT
value).
(*4)–
(*5)
*3: Vdif = { V
IN0
V
OUT0
}
*4: V
IN0
= The input voltage when V
OUT0
appears as input voltage is gradually decreased.
*5: V
OUT0
= A voltage equal to 98% of the output voltage whenever an amply stabilized I
OUT
{V
OUT(T)
+ 1.0V} is input.
*6: Refer to “VOLTAGE CHART”.
*7: Unless otherwise stated, V
EN2
=V
IN
for the XC6412 series.
*8: When the series are the XC6411P and XC6412C series, ‘V
IN
” shown in the conditions represents V
IN1
or V
IN2
.
5
