26-48-1046: Description4 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER; CategoryThe connector; File Size30KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

26-48-1046 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	26-48-1046	-	-	View	Buy Now

26-48-1046 Overview

4 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER

26-48-1046 Parametric

Parameter Name	Attribute value
Contact materials	BRASS
Terminal spacing	3.96 mm
Total number of contacts	4
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	41672
Contact surface matching	tin
Contact coated terminals	tin
Connection Type	Dual board connector
Connector male and female	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	right angle
Installation type	BOARD
Number of load rows	1
Terminal type	welding
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0210

General Information

Part Number:

76650-0210

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

KK-156 Connector Kit

.156 Pitch Single Row Vertical and Right Angle Header and Receptacle, 4 Circuit

KK™

(Molex parts within this kit) EU and China RoHS, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

The KK system of "building block" connectors can be used to create thousands of

different configurations, allowing each user to build a system that is precisely suited

to their application. KK has become known as a versatile interconnecting system

developed to meet the challenge of modularization.

Features and Benefits

• Standard cantilever terminals

• Cantilever design provides high contact

pressure

• Wiping action cleans oxides when

connector is mated

• Locking ramps for improved retention

when mated

Applications

• Vending and Gaming Machines

• Production Equipment

• Industrial Instruments

• Energy and Power

Wire-to-Board

3.96mm (.156")

Receptacle and Header

Vertical and Right Angle

4

4 Amps

250 Volts

24-18 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

26-48-1046 Related Products

	26-48-1046	09-50-3041	26-48-1045	76650-0210
Description	4 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP	4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP
Contact materials	BRASS	NOT SPECIFIED	BRASS	NOT SPECIFIED
Total number of contacts	4	4	4	4
Lead-free	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer Series	41672	2139	41671	2139
Contact surface matching	tin	NOT SPECIFIED	TIN	NOT SPECIFIED
Contact coated terminals	tin	NOT SPECIFIED	TIN	NOT SPECIFIED
Connection Type	Dual board connector	Dual board connector	TWO PART BOARD CONNECTOR	Dual board connector
Connector male and female	Pin	Jack	MALE	Jack
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	NO	MULTIPLE MATING PARTS AVAILABLE
Installation type	BOARD	CABLE	BOARD	CABLE
Number of load rows	1	1	1	1
Terminal type	welding	riveting	SOLDER	riveting
UL flammability code	94V-0	94V-2	94V-0	94V-2
