HPC0402A
Vishay
High Performance, High Precision
Surface Mount 0402 Capacitor
FEATURES
• New technology surface mount capacitor based on a
special semi-conductor process
• Construction reduces the parasitic inductance and
brings the SRF values to ultra-high frequencies
• Capacitance is extremely stable in a wide range of
frequencies from 1MHz to several GHz.
• High Q and low ESR
• Tight tolerance to
±
1% or 0.05pF
• Ultra high SRF
• Low parasitic inductance ( - 0.032nH)
PATENT PENDING
• Capacitance range : 0.1pF to 180pF
ELECTRICAL SPECIFICATIONS
Operating Temperature:
- 55°C to + 125°C
Temperature Coefficient
of Capacitance (TCC):
0
±
30ppm/°C
Insulation Resistance:
Voltage :
Ageing:
10
11
Ω
min
2.5 x rated voltage for 5 seconds
none
APPLICATIONS
• Wireless communications
• Mobile phones
• Cordless phones
• GPS
• VCO
• Filter Networks
• Matching Networks
ENVIRONMENTAL SPECIFICATIONS
Life Test:
Thermal Shock:
Moisture Resistance:
1000 hours, + 125°C @ 2 x
rated voltage
100 Cycles, - 55°C/+ 125°C
240 hours, 85% RH, + 85°C
CAPACITANCE TOLERANCE CODE
FOR LESS THAN 10pF
A
±
0.05pF
B
C
FOR 10pF AND HIGHER
F
±
1%
G
±
2%
J
±
5%
±
0.10pF
±
0.25pF
ORDERING INFORMATION
HPC
MODEL
0402
SIZE
A
TYPE
100
CAPACITANCE VALUE
The first two digits are
significant, the third is a
multiplier. An “R”
indicates a
decimal point.
Examples: 101 = 100pF
4R7 = 4.7pF
G
CAPACITANCE
TOLERANCE
see chart above
X
TERMINATION
X= Tin/ Lead
termination
X
VOLTAGE
1 = 6V
Z = 10V
Y = 16V
X = 25V
T
PACKAGING
T = 10000 pcs.
T5 = 5000 pcs.
T1 = 1000 pcs.
At tape and reel
Document Number: 10117
Revision 19-Aug-03
SiliconRFCap@vishay.com
www.vishay.com
1
HPC0402A
Vishay
DIMENSIONS
L
W
DIMENSION
L
W
INCHES
0.040
±
0.002
0.020
±
0.002
0.016
±
0.004
0.006
±
0.002
0.004
±
0.001
0.028
±
0.002
0.014
±
0.002
0.008
±
0.002
0.010
±
0.002
MILLIMETERS
1.02
±
0.05
0.51
±
0.05
0.40
±
0.10
0.15
±
0.05
0.10
±
0.03
0.71
±
0.05
0.36
±
0.05
0.20
±
0.05
0.25
±
0.05
T
B
FOR 0.1 - 0.5pF
W
A
C
T*
A
A1
B
C
B
FOR 0.6 - 180pF
W
C
D
A1
B
E
D
E
For PAD DESIGN, please see assembly/reflow recommendations page.
*For low profile versions see data sheet HPC0402B/C
CAPACITANCE RANGE AND VOLTAGE
CAP (pF)
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
www.vishay.com
2
CAP CODE
6
0R1
0R2
0R3
0R4
0R5
0R6
0R7
0R8
0R9
1R0
1R2
1R5
1R8
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
SiliconRFCap@vishay.com
Document Number: 10117
Revision 19-Aug-03
10
VOLTAGE (V)
16
25
HPC0402A
Vishay
SRF VS. CAPACITANCE (Typical)
100
SRF (GHz)
10
1
0.1
1
10
CAPACITANCE (pF)
100
1000
ESR VS. FREQUENCY (Typical)
1
18pF
6.8pF
ESR (ohm)
3.3pF
0.1
0.01
0
500
1000
1500
2000
2500
3000
FREQUENCY (MHz)
Q VS. FREQUENCY (Typical)
10000
1000
Q FACTOR
1pF
100
3.3pF
6.8pF
18pF
10
33pF
1
0
500
1000
1500
2000
2500
3000
FREQUENCY (MHz)
www.vishay.com
4
SiliconRFCap@vishay.com
Document Number: 10117
Revision 19-Aug-03
