IHLP-4040DZ-15
Vishay Dale
Low Profile, High Current Inductor
FEATURES
•
Shielded construction.
•
Frequency range up to 5.0MHz.
•
Lowest DCR/µH, in this package size.
• Handles high transient current spikes without saturation.
• Ultra low buzz noise, due to composite construction.
• 100% Lead (Pb)-free and RoHS compliant.
APPLICATIONS
•
PDA/Notebook/Desktop/Server/Video Card applications.
• High current POL converters.
• Low profile, high current power supplies.
Manufactured under one or more of the following:
US Patents; 6,198,375 / 6,204,744 / 6,449,829 / 6,460,244.
Several foreign patents, and other patents pending.
STANDARD ELECTRICAL SPECIFICATIONS
Ω
Ω
Lo
DCR mΩ DCR mΩ HEAT RATINGSATURATION
INDUCTANCE
TYPICAL MAX
CURRENT
CURRENT
3
µ
H
±
20%
25
°
C
25
°
C
DC AMPS
DC AMPS
4
@100KHz, .25V, 0A
TYPICAL
TYPICAL
0.19
0.50
0.60
44
44
0.24
0.36
0.47
0.56
0.78
1.00
1.80
2.0
0.70
0.85
1.10
1.25
1.60
2.20
4.50
5.20
0.80
0.95
1.20
1.35
1.70
2.50
5.00
5.80
38
35
32
30
25
21
15
14
38
35
32
30
25
21
15
14
• Battery powered devices.
• DC/DC converters in distributed power systems.
• DC/DC converter for Field Programmable Gate Arrays (FGPA).
DIMENSIONS
in inches [millimeters]
Typical Pad Layout
0.402
[10.2]
max
0.158
[4.0]
max
0.512
[13.0]
0.158
[4.0]
max
0.091
±
0.01
[2.3
±
0.3]
0.236
[6.0]
NOTES:
1. All test data is referenced to 25°C ambient.
2. Operating Temperature Range - 55°C to + 125°C
3. DC current (A) that will cause an approximate
∆T
of 40°C.
4. DC current (A) that will cause Lo to drop approximately 20%
5. The part temperature (ambient + temp rise) should not exceed
125°C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application.
0.128
±
0.01
[3.25
±
0.3]
0.453
[11.5]
max
DESCRIPTION
IHLP-4040DZ-15
MODEL
0.36
µ
H
INDUCTANCE
VALUE
±
20%
INDUCTANCE
TOLERANCE
ER
PACKAGE
CODE
e3
JEDEC LEAD FREE
STANDARD
GLOBAL PART NUMBER
I
H
L
P
4
0
4
SIZE
0
D
Z
E
R
R
3
6
M
INDUCTANCE
TOLERANCE
1
5
SERIES
MODEL
PACKAGE
CODE
INDUCTANCE
VALUE
Document Number 34180
Revision 07-Sep-05
For technical questions, contact Magnetics@vishay.com
www.vishay.com
15
