^s.mi-donau.ctoi iPioaucti, One.
20 STERN AVE.
SPRINGFIELD, NEW JERSEY 07081
U.S.A.
Silicon Power Rectifier
1N1199A/B-1N1206A/B
Dim
TELEPHONE: (973) 376-2922
(212) 227-6005
FAX: (973) 376-8960
Millimeter
1
Inches
Minimum Maximum Minimum Maximum Notes
A
B
C
D
E
F
G
H
J
M
N
P
.424
.600
.422
.075
.163
.020
.070
Notes:
1. 10-32 UNF3A
2. Full threads within 2 1/2
threads
3. Standard Polarity: Stud is
Cathode
Reverse Polarity: Stud is
Anode
.437
.505
.800
.453
.175
.405
,189
.310
.350
.065
.100
10.77
15.24
10.72
1.91
4.15
.510
1.78
11.10
12.82
20.32
11.50
4.44
10.29
4.80
7.87
8.89
1.65
2.54
2
Did
Dia
D02Q5AA (D04)
Catalog Numoer
Standard
*S20410
Peak Reverse
Voltage
50V
100V
150V
*S20420
200V
300V
*S20440
400V
500V
*S20460
600V
*S20480
800V
•S204100
1000V
*S204120
1200V
*Change S to R in part number for Reverse Polarity
For JEDEC numbers add R to port number for Reverse
Polarity NOTE: The Reverse Polarity For the A & B versions
may be listed as RA or RB instead of AR or BR
JEDEC
Numbers
1N1199, 1N1199A, 1N1199B
1N1200, 1N1200A, 1N1200B
1N1201, 1N1201A, 1N1201B
1N1202, 1N1202A, 1N1202B
1N1203, 1N1203A, 1N1203B
1N1204, 1N1204A, 1N1204B
1N1205, 1N1205A, 1N1205B
1 Ml 206, 1N1206A, 1N1206B
• Glass Passivated Die
• Low Forward Voltage
• 250A Surge Rating
• Glass to metal seal construction
•
V
RRM to 1 200V
Electrical Characteristics
Average forward current
Maximum surge current
Max 12 t for fusing
Max peak forward voltage
Max peak reverse current
Max peak reverse current
Max Recommended Operating Frequency
IF(AV) 12 Amps
1 FSM 250 Amps
I
2
t 260 A2s
V
FM 1.2 Volts
I RM 10
p
A
!
RM 1.0 mA
10kHz
= 170°C, half sine wave.
R
9JC = 2.5°C/W
8.3ms, half sine,
T
J = 200°C
IFM = 30A:Tj = 25° C *
v
RRMjj = 25°C
V
RRM,
T
J = 150°C*
T
C
•Pulse test: Pulse width 300 ^sec. Duty cycle 2%
Thermal and Mechanical Characteristics
Storage temperature range
Operating junction temp range
Maximum thermal resistance
Mounting torque
Weight
TSTG
Tj
R
9JC
-65°C to 200° C
-65°C to 200°C
2.5°C/W Junction to Case
25-30 inch pounds
.16 ounces {5.0 grams) typical
\n
reserves (he right
la
change hat conditions, parameter limits nnd patkuge dimensions without notice
Inf'ormiilion lurrmned by Nl Sumi-t unduclon it believed to h« both accurmc nnd reliable .it the lime i>( goinj 10 prew. However
NI
Soni-l nndutliirs iv,unics m>
rcvpi'inibility
far
;my errt'f*
or ninivsiiiiH
Jiscuvcred in its n>e
NJ
Seiiii-CondiKli rs
cnvouraiies
ii--r<ji'cr^ tn vuih ih ii J:ii:v hfcla .IKcurrenthefrre plncing.irikn
