30CTQG100STRL

Description
Schottky Rectifier, 2 x 15 A
File Size125KB,6 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet View All

30CTQG100STRL Overview

Schottky Rectifier, 2 x 15 A

30CTQ...GSPbF/30CTQ...G-1PbF
Vishay High Power Products
Schottky Rectifier, 2 x 15 A
30CTQ...GSPbF
30CTQ...G-1PbF
FEATURES
• 175 °C T
J
operation
• Center tap configuration
• Low forward voltage drop
• High frequency operation
• High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
• Guard ring for enhanced ruggedness and long term
reliability
• Lead (Pb)-free (“PbF” suffix)
• Designed and qualified for industrial level
Available
RoHS*
COMPLIANT
Base
common
cathode
2
Base
common
cathode
2
2
1 Common
3
Anode cathode Anode
2
1 Common
3
Anode cathode Anode
DESCRIPTION
This center tap Schottky rectifier series has been optimized
for low reverse leakage at high temperature. The proprietary
barrier technology allows for reliable operation up to 175 °C
junction temperature. Typical applications are in switching
power supplies, converters, freewheeling diodes, and
reverse battery protection.
D
2
PAK
TO-262
PRODUCT SUMMARY
I
F(AV)
V
R
2 x 15 A
80/100 V
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
F(AV)
V
RRM
I
FSM
V
F
T
J
t
p
= 5 µs sine
15 Apk, T
J
= 125 °C (per leg)
Range
CHARACTERISTICS
Rectangular waveform
VALUES
30
80/100
650
0.69
- 55 to 175
UNITS
A
V
A
V
°C
VOLTAGE RATINGS
PARAMETER
Maximum DC reverse voltage
Maximum working peak reverse voltage
SYMBOL
V
R
V
RWM
30CTQ080GSPbF
30CTQ080G-1PbF
80
30CTQ100GSPbF
30CTQ100G-1PbF
100
UNITS
V
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Maximum average
forward current
See fig. 5
per device
I
F(AV)
per leg
5 µs sine or 3 µs rect. pulse
I
FSM
10 ms sine or 6 ms rect. pulse
E
AS
I
AR
Following any rated load
condition and with rated
V
RRM
applied
50 % duty cycle at T
C
= 129 °C, rectangular waveform
15
A
Maximum peak one cycle non-repetitive
surge current per leg
See fig. 7
Non-repetitive avalanche energy per leg
Repetitive avalanche current per leg
650
210
7.50
0.50
mJ
A
SYMBOL
TEST CONDITIONS
VALUES
30
UNITS
T
J
= 25 °C, I
AS
= 0.50 A, L = 60 mH
Current decaying linearly to zero in 1 µs
Frequency limited by T
J
maximum V
A
= 1.5 x V
R
typical
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 94191
Revision: 13-Aug-08
For technical questions, contact: diodes-tech@vishay.com
www.vishay.com
1
