MMR
Features
Self Healing
Low ESR
Radial leaded metallized
polyester film capacitors
Small size
Low cost
Applications
General Purpose
Bypass
Coupling
Blocking
Specifications
Operating Temperature Range
Capacitance Tolerance
Peak, AC voltage (50/60 Hz)
Dissipation Factor (MAX)
25°C
Insulation Resistance
@25°C (<70% RH)for 1 minute at
100VDC applied
Load Life
-40°C to +105°C
+10% at 1 kHz, 25°C
+5% optional
WVDC
100
250
400
630
VAC
63
160
200
220
For T>+85°C , The voltage must be decreased by 1.25% per °C
Frequency (kHz)
Dissipation Factor
1
1.0%
10
1.5%
Capacitance
Insulation Resistance
<0.33μF
9000 MΩ
>0.33μF
3000 MΩxμF
2000 Hours, +85C with 125% of rated voltage
Capacitance Change
<5% of initially measured value
Dissipation Factor
<0.005 at 1kHz and 25°C
Insulation Resistance
>50% of maximum specified value
1000 Hours, 93%RH(+/-2%), +40°C and no voltage applied
Capacitance Change
<5% of initially measured value
Dissipation Factor
<0.005 at 1kHz and 25°C
Insulation Resistance
>50% of maximum specified value
<1 nano-Henry per mm of body length and lead length
<1.0% after 2 years at 40°C
+400 ppm/°C, +200ppm/°C
Terminal to Terminal
160% of VDC applied for 2 Seconds and 25°C
Polyester
Metallized film
Flame Retardant epoxy resin (UL94V0)
Lead free tinned copper leads
Damp Heat test
Self Inductance
Capacitance Drift Factor
Capacitance Temperature
Coefficient
Dielectric Strength
Dielectric
Construction
Coating
Leads
L MAX
S+1.0
G MAX
d +0.05
10.5
7.5
1.5
0.6
12
10
1.5
0.6
18.5
15
1.5
0.8
26
22.5
1.5
0.8
31
27.5
1.5
0.8
