201UR105B datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 201UR105B

201UR105B: DescriptionTrimmer, Carbon Composition, 0.25W, 1000000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15 MM, 3 PINS, ROHS COMPLIANT; CategoryPassive components The resistor; File Size3MB，2 Pages; ManufacturerCTS; Environmental Compliance

Download Datasheet Parametric Compare View All

201UR105B Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	201UR105B	-	-	View	Buy Now

201UR105B Overview

Trimmer, Carbon Composition, 0.25W, 1000000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15 MM, 3 PINS, ROHS COMPLIANT

201UR105B Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	CTS
package instruction	15 MM, 3 PINS, ROHS COMPLIANT
Reach Compliance Code	compli
ECCN code	EAR99
Actuator direction	HORIZONTAL
Actuator type	SCREW
structure	Miniature Size
Installation features	THROUGH HOLE MOUNT
Number of terminals	3
number of turns	1
Maximum operating temperature	100 °C
Minimum operating temperature	55 °C
Package diameter	15.08 mm
Package length	4.98 mm
Package shape	CIRCULAR PACKAGE
Package form	PCB Mou
Rated power dissipation(P)	0.25 W
Rated temperature	55 °C
resistance	1000000 Ω
resistance law	LINEAR
Resistor type	TRIMMER
rotation angle	260 deg
surface mount	NO
technology	CARBON COMPOSITION
Terminal shape	SNAP-IN
Tolerance	20%
Operating Voltage	350 V

Preview

Download Datasheet

View All

Electrocomponents

Series 201

Data Sheet

Trimmer Potentiometer

Commercial

15 mm Diameter

Carbon Composition

Trimmer Potentiometer

Features

• Miniature size — knob 19/32" (15.08mm)

diameter

• Printed circuit mounting with knob parallel

or perpendicular to printed circuit board

• Wide resistance range

• Knob slotted for screwdriver adjustment

• Reliable CTS composition resistance element

• Low cost

• RoHS compliant

Electrical and Mechanical Specifications

Resistance Range

500Ω through 5 Megohms

Fixed resistor available

Resistance Tolerance

±30%, ±20%, ±10%

Power Rating, Watts

watt @ 55°C

( resistance up to 5000Ω )

Stop Strength

in-lb (2.9 kgf-cm min.)

Adjusting Knob Information

Diameter: 19/32" (15.08mm)

Trim:

Knob Periphery

Knob Adjustmeent

Slotted — front or rear screwdriver adjust

CTS Type

201 R

Standard:

Smooth round

Standard Color:

Blue

watt @ 55°C

( resistance above 5000Ω )

Voltage Rating

350 VDC

Angle of Rotation

260°

Turning Torque

Standard: 3/4 to 6 in-oz (54 – 432 gf-cm)

Special : 2 to 7 in-oz (144 – 505 gf-cm)

Operating Temperature

-35°C

85°C

Mounting Information

Type 201U for mounting control with knob parallel to printed

circuit board.

Type 201X for mounting control with knob perpendicular to

printed circuit board.

1-2

CTS

Electrocomponents

11/13/13

www.ctscorp.com

201UR105B Related Products

	201UR105B	201UR102B	201XR254B	201XR103B	201UR252B	201UR503B	201XR252B	201UR253B	201UR254B
Description	Trimmer, Carbon Composition, 0.25W, 1000000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15 MM, 3 PINS, ROHS COMPLIANT	Trimmer, Carbon Composition, 0.2W, 1000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15 MM, 3 PINS, ROHS COMPLIANT	Trimmer, Carbon Composition, 0.25W, 250000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15.08 MM, ROUND, 3 PINS	Trimmer, Carbon Composition, 0.25W, 10000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15 MM, 3 PINS, ROHS COMPLIANT	Trimmer, Carbon Composition, 0.2W, 2500ohm, 350V, 20% +/-Tol, 1 Turn(s), 15.08 MM, ROUND, 3 PINS	Trimmer, Carbon Composition, 0.25W, 50000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15.08 MM, ROUND, 3 PINS, ROHS COMPLIANT	Trimmer, Carbon Composition, 0.2W, 2500ohm, 350V, 20% +/-Tol, 1 Turn(s), 15.08 MM, ROUND, 3 PINS	Trimmer, Carbon Composition, 0.25W, 25000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15.08 MM, ROUND, 3 PINS	Trimmer, Carbon Composition, 0.25W, 250000ohm, 350V, 20% +/-Tol, 1 Turn(s), 15.08 MM, ROUND, 3 PINS
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	15 MM, 3 PINS, ROHS COMPLIANT	PCB Mount,	PCB Mount,	PCB Mount,	PCB Mount,	PCB Mount,	PCB Mount,	15.08 MM, ROUND, 3 PINS	15.08 MM, ROUND, 3 PINS
Reach Compliance Code	compli	compli	compli	compli	compli	compli	compli	compli	compli
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Actuator direction	HORIZONTAL	HORIZONTAL	HORIZONTAL	VERTICAL	VERTICAL	VERTICAL	HORIZONTAL	VERTICAL	VERTICAL
Actuator type	SCREW	SCREW	SCREW	SCREW	SCREW	SCREW	SCREW	SCREW	SCREW
structure	Miniature Size	Miniature Size	Slotted Knob	Miniature Size	Slotted Knob	Miniature Size	Slotted Knob	Slotted Knob	Slotted Knob
Installation features	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT
Number of terminals	3	3	3	3	3	3	3	3	3
number of turns	1	1	1	1	1	1	1	1	1
Maximum operating temperature	100 °C	85 °C	100 °C	100 °C	85 °C	100 °C	85 °C	100 °C	100 °C
Minimum operating temperature	55 °C	55 °C	55 °C	55 °C	55 °C	55 °C	55 °C	55 °C	55 °C
Package diameter	15.08 mm	15.08 mm	15.08 mm	15.08 mm	15.08 mm	15.08 mm	15.08 mm	15.08 mm	15.08 mm
Package length	4.98 mm	4.98 mm	4.98 mm	4.98 mm	12.7 mm	4.98 mm	4.98 mm	12.7 mm	12.7 mm
Package shape	CIRCULAR PACKAGE	CIRCULAR PACKAGE	CIRCULAR PACKAGE	CIRCULAR PACKAGE	CIRCULAR PACKAGE	CIRCULAR PACKAGE	CIRCULAR PACKAGE	CIRCULAR PACKAGE	CIRCULAR PACKAGE
Package form	PCB Mou	PCB Mou	PCB Mou	PCB Mou	PCB Mou	PCB Mou	PCB Mou	PCB Mou	PCB Mou
Rated power dissipation(P)	0.25 W	0.2 W	0.25 W	0.25 W	0.2 W	0.25 W	0.2 W	0.25 W	0.25 W
Rated temperature	55 °C	55 °C	55 °C	55 °C	55 °C	55 °C	55 °C	55 °C	55 °C
resistance	1000000 Ω	1000 Ω	250000 Ω	10000 Ω	2500 Ω	50000 Ω	2500 Ω	25000 Ω	250000 Ω
resistance law	LINEAR	LINEAR	LINEAR	LINEAR	LINEAR	LINEAR	LINEAR	LINEAR	LINEAR
Resistor type	TRIMMER	TRIMMER	TRIMMER	TRIMMER	TRIMMER	TRIMMER	TRIMMER	TRIMMER	TRIMMER
rotation angle	260 deg	260 deg	260 deg	260 deg	260 deg	260 deg	260 deg	260 deg	260 deg
surface mount	NO	NO	NO	NO	NO	NO	NO	NO	NO
technology	CARBON COMPOSITION	CARBON COMPOSITION	CARBON COMPOSITION	CARBON COMPOSITION	CARBON COMPOSITION	CARBON COMPOSITION	CARBON COMPOSITION	CARBON COMPOSITION	CARBON COMPOSITION
Tolerance	20%	20%	20%	20%	20%	20%	20%	20%	20%
Operating Voltage	350 V	350 V	350 V	350 V	350 V	350 V	350 V	350 V	350 V
Terminal shape	SNAP-IN	SNAP-IN	SNAP-IN	SNAP-IN	-	-	SNAP-IN	-	-
Base Number Matches	-	1	1	1	1	1	1	-	-
