2SA1020L-O
2SA1020L-Y
Features
•
•
•
•
•
•
•
Halogen
free available upon request by adding suffix "-HF"
Collector of 0.9Watts of Power Dissipation.
Collector-current -2.0A
Operating and storage junction temperature range: -55 to +150
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Lead Free Finish/Rohs Compliant ("P"Suffix designates
RoHS Compliant. See ordering information)
Parameter
Collector-Emitter Breakdown Voltage
(I
C
=-10mAdc, I
B
=0)
Collector-Base Breakdown Voltage
(I
C
=-100uAdc, I
E
=0)
Emitter-Base Breakdown Voltage
(I
E
=-100mAdc, I
C
=0)
Collector Cutoff Current
(V
CB
=-50Vdc, I
E
=0)
Emitter Cutoff Current
(V
EB
=-5.0Vdc, I
C
=0)
DC Current Gain
(I
C
=-0.5Adc, V
CE
=-2.0Vdc)
DC Current Gain
(I
C
=-1.5Adc, V
CE
=-2.0Vdc)
Collector-Emitter Saturation Voltage
(I
C
=-1Adc, I
B
=-50mAdc)
Base-Emitter Saturation Voltage
(I
C
=-1.0Adc,
I
B
=-50mA)
Transistor Frequency
(I
C
=-500mAdc, V
CE
=-2.0Vdc,)
Coll ector output capacitance
(I
E
=0, V
CB
=-10Vdc,f=1MHz)
Turn-0n time
(I
B1
=-I
B2
=-0.05,
V
CC
=-30Vdc,I
C
=-1Adc)
Storage time
(I
B1
=-I
B2
=-0.05,
V
CC
=-30Vdc,I
C
=-1Adc)
Fall time
(I
B1
=-I
B2
=-0.05,
V
CC
=-30Vdc,I
C
=-1Adc)
Min
-50
-50
-5.0
---
---
70
40
---
---
Max
---
---
---
-1.0
-1.0
240
---
-0.5
-1.2
100(Typ)
40(Typ)
0.1(Typ)
1.0(Typ)
0.1(Typ)
Units
Vdc
Vdc
Vdc
uAdc
uAdc
---
---
Vdc
Vdc
MHz
pF
us
us
us
DIM
A
B
C
D
E
F
G
H
J
K
L
M
DIMENSIONS
INCHES
MIN
MAX
MIN
MAX
3.700
4.100
.146
.161
4.000
---
.157
---
0.000
0.300
0.000
0.012
0.350
0.450
.014
.018
1.280
1.580
.050
.062
4.700
5.100
.185
.201
7.800
8.200
.307
.323
13.80
14.20
.543
.559
.600
.800
.024
.031
0.350
.550
.014
.022
1.270
.050
2.200
2.800
.086
.110
2.440
2.640
.096
.104
4.400
5.600
.173
.220
MM
PNP
Plastic-Encapsulate
Transistor
TO-92L
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Symbol
V
(BR)CEO
V
(BR)CBO
V
(BR)EBO
I
CBO
I
EBO
h
FE(1)
h
FE(2)
V
CE(sat)
V
BE(sat)
f
T
C
ob
t
on
ts
tf
E
E
C
B
C
B
STRAIGHT LEAD BENT LEAD
BULK PACK
AMMO PACK
NOTE
CLASSIFICATION OF H
FE (1)
Rank
Range
O
70-140
Y
120-240
Straight Lead
Bent Lead
Straight Lead
Bent Lead
* For ammo packing detailed specification, click here to visit our website
of product packaging for details.
www.mccsemi.com
Revision:
C
1 of 2
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-AP
Part Number-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-BP-HF
Packing
Ammo Packing:
2Kpcs/Ammo
Box
Bulk:
50Kpcs/Carton
