1206NF820202CG Overview

Ceramic Capacitor, Ceramic,

1206NF820202CG Parametric

Parameter Name	Attribute value
Maker	Walsin Technology Corporation
package instruction	,
Reach Compliance Code	compli
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
Manufacturer's serial number	1206
Number of terminals	2

Preview

Download Datasheet

View All

Approval sheet

Middle and High Voltage Series (200V to 3kV)

MULTILAYER CERAMIC CAPACITORS

Middle & High Voltage Series (200V to 3kV)

0603 to 1812 Sizes

NP0, X7R & Y5V Dielectrics

RoHS compliance

*Contents in this sheet are subject to change without prior notice.

Page 1 of 13

ASC_Middle & High Voltage_003Y

Mar. 2014

Approval sheet

Middle and High Voltage Series (200V to 3kV)

1. INTRODUCTION

WTC middle and high voltage series MLCC is designed by a special internal electrode pattern, which can reduce

voltage concentrations by distributing voltage gradients throughout the entire capacitor. This special design also affords

increased capacitance values in a given case size and voltage rating.

Chips size 1206 and larger to use on reflow soldering process only. Capacitors with X7R dielectrics are not

intended for AC line filtering applications. Capacitors may require protective surface coating to prevent external arcing.

2. FEATURES

High voltage in a given case size.

High stability and reliability.

3. APPLICATIONS

Snubbers in high frequency power converters.

High voltage coupling/DC blocking.

DC-DC converters.

Back-lighting inverters

4. HOW TO ORDER

1808

Size

Inch (mm)

0603

(1608)

0805

(2012)

1206

(3216)

1210

(3225)

1808

(4520)

1812

(4532)

Dielectric

N=NP0

(C0G)

B=X7R

F=Y5V

100

Capacitance

Two significant

digits followed by

no. of zeros. And R

is in place of

decimal point.

eg.:

0R5=0.5pF

1R0=1.0pF

100=10x10

=10pF

Tolerance

B=±0.1pF

C=±0.25pF

D=±0.5pF

F=±1%

G=±2%

J=±5%

K=±10%

M=±20%

Z=-20/+80%

202

Rated voltage

Termination

Packaging

Two significant digits

C=Cu/Ni/Sn

(for NP0,

T=7”

reeled

followed by no. of zeros. X7R, Y5V dielectric)

G=13”

reeled

And R is in place of

decimal point.

201=200

VDC

251=250

VDC

501=500

VDC

631=630

VDC

102=1000

VDC

202=2000

VDC

302=3000

VDC

* Partial NP0 items are with Ag/Ni/Sn terminations, please ref to below product range of NP0 dielectric for detail.

Page 2 of 13

ASC_Middle & High Voltage_003Y

Mar. 2014

Approval sheet

Middle and High Voltage Series (200V to 3kV)

5. EXTERNAL DIMENSIONS

Size

Inch (mm)

0603(1608)

L (mm)

1.60±0.10

1.60

+0.15/-0.10

2.00±0.15

W (mm)

0.80±0.10

0.80

+0.15/-0.10

1.25±0.10

T (mm)/Symbol

0.80±0.07

0.80

+0.15/-0.10

0.60±0.10

0.80±0.10

1.25±0.10

0.80±0.10

1206 (3216)

3.20±0.15

3.20±0.20

3.20±0.30

1210 (3225)

3.20±0.40

1808 (4520)

4.50+0.5/-0.3

2.50±0.30

2.03±0.25

1.60±0.15

1.60±0.20

2.50±0.20

0.95±0.10

1.25±0.10

1.60±0.20

0.95±0.10

1.25±0.10

1.60±0.20

2.50±0.30

1.25±0.10

2.00±0.20

1.25±0.10

1.60±0.20

2.00±0.20

2.50±0.30

2.80±0.30

0.50±0.25

0.75±0.25

0.60±0.20

(0.5±0.25)*

0.40±0.15

Remark

(mm)

0805 (2012)

0.50±0.20

Fig. 1 The outline of MLCC

3.20±0.30

1812 (4532)

4.50+0.5/-0.3

3.20±0.40

# Reflow soldering only is recommended.

* For 1206_1000V ~3000V products.

0.50±0.25

6. GENERAL ELECTRICAL DATA

Dielectric

Size

Capacitance*

NP0

0.5pF to 6800pF

Cap≤5pF: C (±0.25pF)

5pF<Cap<10pF: D (±0.5pF)

Cap≥10pF: F (±1%), G (±2%),

J (±5%),K (±10%)

200V to 3kV

Cap<30pF: Q≥400+20C

Cap≥30pF: Q≥1000

DF≤2.5%

X7R

100pF to 1.0µF

Y5V

0805, 1206, 1210, 1812

0.01µF to 0.68µF

0603, 0805, 1206, 1210, 1808, 1812

Capacitance tolerance***

K (±10%), M (±20%)

Z (-20/+80%)

Rated voltage (WVDC)

Q/DF*

Insulation resistance at Ur**

200V, 250V

DF≤5%

Ur=200~630V:

≥10GΩ

or RxC≥100Ω-F whichever is smaller

Ur=1000~3000V:

≥10GΩ

200~300V:

≥2

x WVDC

500~999V:

≥1.5

x WVDC

1000~3000V:

≥1.2

x WVDC

-55 to +125°C

±30ppm

±15%

Ni/Sn (lead-free termination)

-25 to +85°C

+30/-80%

Dielectric strength

Operating temperature

Capacitance characteristic

Termination

* Measured at the condition of 30~70% related humidity.

NP0: Apply 1.0±0.2Vrms, 1.0MHz±10% for Cap≤1000pF and 1.0±0.2Vrms, 1.0kHz±10% for Cap>1000pF, 25°C at ambient temperature

X7R, X5R: Apply 1.0±0.2Vrms, 1.0kHz±10%, at 25°C ambient temperature.

Y5V: Apply 1.0±0.2Vrms, 1.0kHz±10%, at 20°C ambient temperature.

** Preconditioning for Class II MLCC: Perform a heat treatment at 150±10°C for 1 hour, then leave in ambient condition for 24±2 hours

before measurement.

Page 3 of 13

ASC_Middle & High Voltage_003Y

Mar. 2014

Approval sheet

Middle and High Voltage Series (200V to 3kV)

7. CAPACITANCE RANGE (MIDDLE VOLTAGE - 200V to 630V)

7-1 NP0 Dielectric

DIELECTRIC

NP0

SIZE

0603

0805

1206

1210

1808

1812

RATED VOLTAGE

200 250 200 250 500 630 200 250 500 630 200 250 500 630 500 630 200 250 500 630

(VDC)

0.5pF (0R5)

1.0pF (1R0)

1.2pF (1R2)

1.5pF (1R5)

1.8pF (1R8)

2.2pF (2R2)

2.7pF (2R7)

3.3pF (3R3)

3.9pF (3R9)

4.7pF (4R7)

5.6pF (5R6)

6.8pF (6R8)

8.2pF (8R2)

10pF (100)

12pF (120)

15pF (150)

18pF (180)

22pF (220)

27pF (270)

33pF (330)

39pF (390)

47pF (470)

56pF (560)

68pF (680)

82pF (820)

100pF (101)

120pF (121)

150pF (151)

180pF (181)

220pF (221)

270pF (271)

330pF (331)

390pF (391)

470pF (471)

560pF (561)

680pF (681)

820pF (821)

1,000pF (102)

1,200pF (122)

1,500pF (152)

1,800pF (182)

2,200pF (222)

2,700pF (272)

3,300pF (332)

3,900pF (392)

4,700pF (472)

5,600pF (562)

6,800pF (682)

1. The letter in cell is expressed the symbol of product thickness.

Page 4 of 13

Capacitance

ASC_Middle & High Voltage_003Y

Mar. 2014

Approval sheet

Middle and High Voltage Series (200V to 3kV)

7-2 X7R Dielectric

DIELECTRIC

SIZE

0603

RATED VOLTAGE

200 250

(VDC)

100pF (101)

120pF (121)

150pF (151)

180pF (181)

220pF (221)

270pF (271)

330pF (331)

390pF (391)

470pF (471)

560pF (561)

680pF (681)

820pF (821)

1,000pF (102)

1,200pF (122)

1,500pF (152)

1,800pF (182)

2,200pF (222)

2,700pF (272)

3,300pF (332)

3,900pF (392)

4,700pF (472)

5,600pF (562)

6,800pF (682)

8,200pF (822)

0.010µF (103)

0.012µF (123)

0.015µF (153)

0.018µF (183)

0.022µF (223)

0.027µF (273)

0.033µF (333)

0.039µF (393)

0.047µF (473)

0.056µF (563)

0.068µF (683)

0.082µF (823)

0.10µF (104)

0.12µF (124)

0.15µF (154)

0.18µF (184)

0.22µF (224)

0.27µF (274)

0.33µF (334)

0.39µF (394)

0.47µF (474)

0.56µF (564)

0.68µF (684)

0.84µF (844)

1.0µF (105)

Capacitance

X7R

0805

200 250 500

630

1206

1210

1808

1812

200 250 500 630 200 250 500 630 500 630 200 250 500 630

1. The letter in cell is expressed the symbol of product thickness.

Page 5 of 13

ASC_Middle & High Voltage_003Y

Mar. 2014
