MS27496
Front, Box Mounting Receptacle
AE196
Bayonet Coupling, Crimp Removable, Rear Release, Scoop-Proof
1.104(28.04)
MAX
A
MASTER KEYWAY
38999 S I
B
D
F
.060(1.52)
MAX GROMMET EXTENSION
E
MAX
GROMMET
H
MAX
G
4x
C
4X MINOR KEYWAYS
.312(7.93)
MAX
BLUE COLOR BAND
Page 5
Page 15
Pages 19–21
Page 4
Pages 16-18
Page 13
Completed Part Number
Contacts, Sealing Plugs and Tools
Insert Arrangements
Performance Specifications
Insert Availability and Contact Information
Polarization
A
Shell
Size
9
11
13
15
17
19
21
23
25
±.020
inch
.938
1.031
1.125
1.219
1.312
1.438
1.562
1.688
1.812
±.51
mm
23.83
26.19
28.58
30.96
33.32
36.53
39.67
42.88
46.02
inch
.719
.812
.906
.969
1.062
1.156
1.250
1.375
1.500
B
(TP)
mm
18.26
20.62
23.01
24.61
26.97
29.36
31.75
34.93
38.10
inch
.128
.128
.128
.128
.128
.128
.128
.147
.147
Ø
C
+.010
-.005
+.25
-.13
mm
3.25
3.25
3.25
3.25
3.25
3.25
3.25
3.73
3.73
+.000
-.005
inch
.632
.632
.632
.632
.632
.632
.602
.602
.602
D
+.00
-.13
mm
16.05
16.05
16.05
16.05
16.05
16.05
15.29
15.29
15.29
inch
.572
.700
.850
.975
Ø
E
+.001
-.005
+.03
-.13
mm
14.53
17.78
21.59
24.77
27.94
30.66
33.83
37.01
40.18
+.015
-.000
inch
.085
.085
.085
.085
.085
.085
.115
.115
.115
F
+.38
-.00
mm
2.16
2.16
2.16
2.16
2.16
2.16
2.92
2.92
2.92
inch
.469
.594
.719
.844
.969
Ø
G
Maximum
mm
11.91
15.09
18.26
21.44
24.61
27.38
30.56
33.73
36.91
Ø
H
Maximum
inch
.299
.427
.541
.666
.791
.897
1.022
1.147
1.272
mm
7.59
10.85
13.74
16.92
20.09
22.78
25.96
29.13
32.31
1.100
1.207
1.332
1.457
1.582
1.078
1.203
1.328
1.453
