SMD Voltage Controlled Crystal Oscillators
DSV531S/DSV532S SERIES
■Features
●
5032
size, 1.2mm high. Miniature SMD-VCXO
(0.022cc)
●
The product is an analog VCXO which ensures good
variable frequency and a linear changing frequency.
Pb-Free
■Applications
●
DVD,
Actual size
RoHS Compliant
Digital TV, STB, ADSL, BB modem, backbone
transmission equipment
DSV531SV/DSV532SV
1.25∼80MHz
＋3.3±0.3V
＋1.65±1.65V
−40∼＋85℃
−10∼＋70℃
±50×10
−6
max.
±100×10
−6
min. [Positive Slope]
10mA max.
（fo≦60MHz）
15mA max.
（fo＞60MHz）
[No Load]
15pF max.
40∼60% [50％ V
CC
Level]
V
CC
×0.1 max.
V
CC
×0.9 min.
10ns max.
（fo≦50MHz）
6ns max.
（fo＞50MHz）
［10∼90％ V
CC
Level½
2.2ps typ. [σ]
20ps typ.[Peak to peak]
31ps typ. [tDJ+n
＊
tRJ n=14.1(BER=1
＊
10
-12
) (2)]
10ns max.
［10∼90％ V
CC
Level]
15mA max.
[No Load]
DSV531SB/DSV532SB
5∼50MHz
＋5.0±0.5V
＋2.5±2.0V
■ Standard Specification
Item Type
Output Frequency Range
Supply Voltage
Frequency Control Voltage
Storage Temperature Range
Operating Temperature Range
Frequency Tolerance (Includes frequency
tolerance at room temperature.)
Frequency Adjustment Range
Current Consumption
Load Condition
Symmetry
0 Level Output Voltage
1 Level Output Voltage
Rise and Fall Time
Legend
fo
V
CC
Vcont
T_stg
T_use
f_tol
f_cont
I
CC
L_
CMOS
SYM
V
OL
V
OH
tr, tf
tRMS
tp-p
tTL
tpj
Period Jitter (1)
Total Jitter (1)
Phase Jitter
Packing Unit
1ps max. [10≦fo＜40MHz、 offset:12kHz∼5MHz
fo
fo≧40MHz、 offset:12kHz∼20MHz]
fo
−
1000pcs./reel
（φ180）
Consult our sales representative for other specifications.
（1）
Measured WAVECREST DTS-2075
（２） ：
tDJ Deterministic jitter tRJ Random jitter
：
■ Dimensions[mm]
5.0±0.2
Frequency
（A+kHz）
#3
3.2±0.2
DSV531S SERIES
Model Code
DSV531SV→V531SV
DSV531SB→V531SB
Pin Connections
Pin No. Connection
#1
Vcont
GND
#2
Output
#3
V
CC
#4
Model Code
＃4
5.0±0.2
Frequency
（A+kHz）
＃3
DSV532S SERIES
Model Code
DSV532SV→V532SV
DSV532SB→V532SB
Pin Connections
Pin No. Connection
#1
Vcont
GND
#2
Output
#3
V
CC
#4
#4
#1
#1 index
1.2±0.2
#2
Logo
Lot No.
3.2±0.2
＃1
#1 Index
Logo
＃2
Lot No.
■ Recommended Land Pattern
〈Top View〉
3.83
3.9
+0.1
1.1
−0.2
■ Recommended Land Pattern
〈Top View〉
2.54
#1
#2
2.54
#1
#2
2.33
2.4
2.1
0.9
2.2
0.73
1.03
1.3
1.0
#4
#3
#4
1.2
#3
1.4
1.2
