42820-2213 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 42820-2213

42820-2213: Description2 CONTACT(S), MALE, POWER CONNECTOR, SOLDER; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

42820-2213 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	42820-2213	-	-	View	Buy Now

42820-2213 Overview

2 CONTACT(S), MALE, POWER CONNECTOR, SOLDER

42820-2213 Parametric

Parameter Name	Attribute value
Contact materials	BRASS
Total number of contacts	2
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	42820
Contact surface matching	gold (30)
Contact coated terminals	Tin(100)
Connection Type	power connector
Connector male and female	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation type	BOARD
Shell material	glass filled nylon
Terminal type	welding
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0220

General Information

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

76650-0220

Molex / Waldom

Mini-Fit Sr. Power Connector Kit

Gold Right Angle Header, Plug and Receptacle

Mini-Fit Sr.™

(Molex Parts within this kit) - EU RoHS Compliant, UL, CSA and TUV

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

Need for power connectors above 20 Amps. Lower mating forces with increased

reliability. More current packed into fewer lines. The system is UL, CSA and TUV

approved. -40 Degrees C to +105 Degrees C. These Gold Plated parts do not need

Nyogel coating, as with tin plated parts, to help resist fretting corrosion in

applications where vibration is present.

Features and Benefits

• High current

• Fully polarized, Prevents Mis-Mating

• Positive Locks, Secure Mating, guards

against accidental disengagement of

housings

• Low engagement force for greater ease in

mating

• Includes mandatory Terminal Position

Assurance (TPA) clip

• Fully-Isolated Contacts, Withstand Reflow

Process

• Four points of electrical contact provide

high reliability

• Design Flexibility

• Metal board retention clip

Bill of Materials for Part No. 76650-0220

For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com

Page 1 of 2

(Wire-to-Wire) and (Wire-to-Board)

10mm (.393”)

Plugs and Receptacles

2, 3 and 4

(23 - 33) Amps - Depending on Wire Gauge

600 Volts

12-10 AWG

Applications

• High-end Computers

• Power Supplies, Generators, Battery Chargers

• Factory Automation Machines

• Cellular Base Station

• Air Conditioners

• Telecom Backplane

• Stadium Lighting and Scoreboards

• Medical Equipment

• Power Station

• Deep Well Pumps

• Welders

• Construction Signs

• Other High Amperage Devices

• HVAC

42820-2213 Related Products

	42820-2213	42817-0012	42818-0312	42818-0412	42820-4213	76650-0220	42820-3213	42815-0012
Description	2 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	3 CONTACT(S), MALE, POWER CONNECTOR, CRIMP, PLUG	3 CONTACT(S), MALE, POWER CONNECTOR, CRIMP, PLUG	4 CONTACT(S), MALE, POWER CONNECTOR, CRIMP, PLUG	4 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	3 CONTACT(S), MALE, POWER CONNECTOR, CRIMP, PLUG	3 CONTACT(S), MALE, POWER CONNECTOR, SOLDER	COPPER ALLOY, GOLD (30) FINISH, WIRE TERMINAL
Contact materials	BRASS	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	BRASS	NOT SPECIFIED	BRASS	NOT SPECIFIED
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Manufacturer Series	42820	42818	42818	42818	42820	42818	42820	42815
Terminal type	welding	CRIMP	CRIMP	riveting	welding	CRIMP	SOLDER	Wiring terminal
Total number of contacts	2	3	3	4	4	3	3	-
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	-
Contact surface matching	gold (30)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	gold (30)	NOT SPECIFIED	GOLD (30)	-
Contact coated terminals	Tin(100)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	Tin(100)	NOT SPECIFIED	TIN (100)	-
Connection Type	power connector	POWER CONNECTOR	POWER CONNECTOR	power connector	power connector	POWER CONNECTOR	POWER CONNECTOR	-
Connector male and female	Pin	MALE	MALE	Pin	Pin	MALE	MALE	-
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	-
Installation type	BOARD	PANEL	PANEL	PANEL	BOARD	PANEL	BOARD	-
Shell material	glass filled nylon	POLYESTER	POLYESTER	Polyester	glass filled nylon	POLYESTER	GLASS FILLED POLYAMIDE	-
UL flammability code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	-
