FURF1620CT ........ FURF1660CT
16.0 Amp. Switchmode Power Rectifiers
ITO-220AB
Voltage
200 to 600 V
Current
16.0 A
1
2
3
• Ultrafast 35 and 60 Nanosecond Recovery times
• 175° C operating Junction Temperature
• Popular TO-220 Package
• Epoxy meets UL94, VO @ 1/8"
• High temperature glass passivated junction
• High voltage capability to 600 volts
• Low leakage specified @ 150 °C case temperature
• Current derating @ both case and ambient temperatures
Mechanical Data
PIN 1
PIN 3
CASE
PIN 2
• Case: Epoxy, molded
• Lead temperature for soldering purposes: 260 °C
Max. for 10 seconds
• Finish: all external surfaces corrosion resistant and
terminal leads are readily solderable
• Shipped 50 units per plastic tube
• Weight: 1.9 grams (approximately)
Dimensions in mm.
Absolute Maximum Ratings, according to IEC publication No. 134
FURF1620CT
V
RRM
V
RWM
V
R
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Forward Current
Per Leg
Total Device, (Rated V
R
). T
C
= 150 °C
Total Device
Peak Rectified Forward Current
(Rated VR, Square Wave, 20 KHz), T
C
= 150 °C
Per Diode Leg
Non repetitive Peak Surge Current
(Surge Applied at Rated Load Conditions
Halfwave, Single Phase, 60 Hz)
200 V
FURF1640CT
400 V
FURF1660CT
600 V
I
F(AV)
8.0 A
16 A
16 A
I
FM
I
FSM
T
rr
100 A
Maximum Reverse Recovery Time
I
F
=0.5 A; I
R
= 1 A; I
RR
= 0.25 A
25 nS
50 nS
– 65 to + 175 °C
T
j-
T
stg
Operating Junction Temperature and Storage
Temperature
Electrical Characteristics
FURF1620CT
FURF1640CT
FURF1660CT
V
F
I
R
R
thj-c
Max. Instantaneous Forward Voltage (Note 1)
(IF = 8.0 Amps, T
C
= 25 °C)
(IF = 8.0 Amps, T
C
= 150 °C)
Maximum Instantaneous Reverse Current
at Rated DC Blocking Voltage @ T
A
= 25 ºC
@ T
A
= 125 ºC
Maximum Thermal Resistance, Junction to Case
0.975 V
0.895 V
1.30 V
1.300 V
10 µA
500 µA
2.0 °C/W
1.50 V
1.20 V
5.0 µA
250 µA
3.0 °C/W
Note: 1. Pulse Test: Pulse Width = 300 µs, Duty Cycle
≤2.0%.
Apr - 08
FURF1620CT ........ FURF1660CT
Rating And Characteristic Curves
CURRENT DERATING, CASE,
PER LEG
9.0
8.0
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0
140 145 150 155 160 165 170 175 180
SQUARE WAVE
dc
RATED V
R
APPLIED
TYPICAL FORWARD VOLTAGE,
PER LEG
I
F
, instantaneous forward current (A)
10
I
F(AV)
, average power dissipation (W)
100
70
50
30
20
10
7.0
5.0
3.0
2.0
1.0
0.7
0.5
0.3
0.2
T
j
= 175 ºC
100 ºC
25 ºC
0.1
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2
T
C
, case temperature (ºC)
V
F
, instantaneous voltage (V)
*The curves shown are typical for hightest voltage deice in the
voltage grouping. Typical reverse current for lower voltage selections
can be estimated from these same curves if V
R
is sufficiently below
rated V
R
.
CURRENT DERATING, AMBIENT,
PER LEG
14
TYPICAL CAPACITANCE, PER LEG
1000
I
F(AV)
, average forward current (A)
I
F
, junction capacitance (pF)
12
10
8.0
6.0
4.0
2.0
SQUARE WAVE
SQUARE WAVE
dc
R
th(j-a)
= 16 °C/W
R
th(j-a)
= 60°C/W
(NO HEATSINK)
300
T
j
= 25 ºC
100
dc
30
0
0 20 40 60 80 100 120 140 160 180 200
10
1
10
100
T
A
, ambient temperature (°C)
TYPICAL REVERSE CURRENT
PER LEG
800
400
200
80
40
20
8.0
4.0
2.0
0.8
0.4
0.2
0.08
0.04
0.02
0
0
40
V
R
, reverse voltage (V)
I
R
, reverse current (µA)
T
j
= 175 ºC
100 ºC
25 ºC
80
120
160
200
V
R
, reverse voltage (V)
Apr - 08
