SAFETY
RL-2250
DESCRIPTION
• Two Section Linear Transformer
UL RECOGNIZED
E132629
50/60 HZ TRANSFORMERS
ALL/TRAN™
IEC-950
CERTIFIED
E176740
FEATURES & APPLICATIONS
• Meets or exceeds UL, CSA, VDE and IEC specifications
• Incorporate advanced dual bobbin non-concentric design
that reduces interwinding capacitance and eliminates the
need for electrostatic shielding
• Since the windings are balanced, no primary circulating
currents are present
• Use of high temperature, high stability materials results in
excellent interwinding insulation and insulation between
windings and core
Verify operation with sample in actual circuit. Order samples at www.rencousa.com.
ENVIRONMENTAL DATA
•
•
Storage temperature range:
-55°C to +130°C
Operating temperature range:
-40°C to +130°C
PACKAGING INFORMATION
• Packaging information: pg. 494
MECHANICAL DIMENSIONS
U.S. Standard (mm)
PART NUMBER VA (SIZE)
RL-2250
RL-2250
RL-2250
RL-2250
RL-2250
RL-2250
FRONT VIEW
A
A (MAX.)
1.3125 (33.34)
1.3125 (33.34)
1.5625 (39.69)
1.8750 (47.63)
1.1875 (30.16)
2.5000 (63.50)
B (MAX.)
1.000 (25.40)
1.000 (25.40)
1.140 (28.96)
1.460 (37.08)
1.680 (42.67)
1.900 (48.26)
C (MAX.)
D (MAX.)
E (TYP.)
0.200 (5.08)
0.200 (5.08)
0.200 (5.08)
F (TYP.)
0.250 (6.35)
0.400 (10.16)
0.400 (10.16)
0.275 (6.99)
0.300 (7.62)
2.5
5
10
20
30
56
1.625 (41.28) 1.1250 (28.58)
1.625 (41.28) 1.3750 (34.93)
1.875 (47.63) 1.3750 (34.93)
2.250 (57.15) 1.6250 (41.28) 0.400 (10.16) 0.400 (10.16)
2.625 (66.68) 1.5625 (39.69) 0.550 (13.97)
3.000 (76.20) 1.8125 (46.04) 0.600 (15.24)
BOTTOM VIEW
H
6
SIDE VIEW
C
SCHEMATIC
7
6
4
I
3
1
12
10
9
7
115 V
50/60 Hz
4
3
9
10
D
115 V
50/60 Hz
1
12
7
B
1
1
3
E
F
4
6
G
0.188 MIN.
NOTE: WHITE DOT
INDICATES PIN #1
PIN
DIMENSION
J
CLEARANCE HOLE FOR
OPTIONAL NYLON MTG.
SCREW AND NUT
Primaries and secondaries
are designed to be used
simultaneously. They
must be used either series
or parallel connected
(as one winding).
TRANSFORMERS
RENCO ELECTRONICS INC.
595 International Place, Rockledge, FL 32955-4200 USA • www.rencousa.com • ISO 9001 Certified
Toll Free Engineering Hot Line: 800.645.5828 • P: 321.637.1000 • F: 321.637.1600
RL-2250
Renco Part Number
RL-2250-2.5-10
RL-2250-5.0-10
RL-2250-10-10
RL-2250-20-10
RL-2250-30-10
RL-2250-56-10
RL-2250-2.5-12
RL-2250-5.0-12
RL-2250-10-12
RL-2250-20-12
RL-2250-30-12
RL-2250-56-12
RL-2250-2.5-16
RL-2250-5.0-16
RL-2250-10-16
RL-2250-20-16
RL-2250-30-16
RL-2250-56-16
RL-2250-2.5-20
RL-2250-5.0-20
RL-2250-10-20
RL-2250-20-20
RL-2250-30-20
RL-2250-56-20
RL-2250-2.5-24
RL-2250-5.0-24
RL-2250-10-24
RL-2250-20-24
RL-2250-30-24
RL-2250-56-24
RL-2250-2.5-28
RL-2250-5.0-28
RL-2250-10-28
RL-2250-20-28
RL-2250-30-28
RL-2250-56-28
RL-2250-2.5-36
RL-2250-5.0-36
RL-2250-10-36
RL-2250-20-36
RL-2250-30-36
RL-2250-56-36
TRANSFORMERS
VA (Size)
2.5
5.0
10
20
30
56
2.5
5
10
20
30
56
2.5
5
10
20
30
56
2.5
5
10
20
30
56
2.5
5
10
20
30
56
2.5
5
10
20
30
56
2.5
5
10
20
30
56
SECONDARY RMS RATING
SERIES
PARALLEL
10V C.T. @ 0.25 A
10V C.T. @ 0.50 A
10V C.T. @ 1.00 A
10V C.T. @ 2.00 A
10V C.T. @ 3.00 A
10V C.T. @ 5.60 A
12.6V C.T. @ 0.20 A
12.6V C.T. @ 0.40 A
12.6V C.T. @ 0.80 A
12.6V C.T. @ 1.60 A
12.6V C.T. @ 2.40 A
12.6V C.T. @ 4.40 A
16V C.T. @ 0.15 A
16V C.T. @ 0.31 A
16V C.T. @ 0.62 A
16V C.T. @ 1.25 A
16V C.T. @ 1.90 A
16V C.T. @ 3.50 A
20V C.T. @ 0.12 A
20V C.T. @ 0.25 A
20V C.T. @ 0.50 A
20V C.T. @ 1.00 A
20V C.T. @ 1.50 A
20V C.T. @ 2.80 A
24V C.T. @ 0.10 A
24V C.T. @ 0.21 A
24V C.T. @ 0.42 A
24V C.T. @ 0.83 A
24V C.T. @ 1.25 A
24V C.T. @ 2.33 A
28V C.T. @ 0.09 A
28V C.T. @ 0.18 A
28V C.T. @ 0.36 A
28V C.T. @ 0.72 A
28V C.T. @ 1.06 A
28V C.T. @ 2.00 A
36V C.T. @ 0.07 A
36V C.T. @ 0.14 A
36V C.T. @ 0.28 A
36V C.T. @ 0.56 A
36V C.T. @ 0.82 A
36V C.T. @ 1.56 A
5V @ 0.50 A
5V @ 1.00 A
5V @ 2.00 A
5V @ 4.00 A
5V @ 6.00 A
5V @ 11.20 A
6.3V @ 0.40 A
6.3V @ 0.80 A
6.3V @ 1.60 A
6.3V @ 3.20 A
6.3V @ 4.80 A
6.3V @ 8.80 A
8V @ 0.30 A
8V @ 0.62 A
8V @ 1.25 A
8V @ 2.50 A
8V @ 3.80 A
8V @ 7.00 A
10V @ 0.24 A
10V @ 0.50 A
10V @ 1.00 A
10V @ 2.00 A
10V @ 3.00 A
10V @ 5.60 A
12V @ 0.20 A
12V @ 0.42 A
12V @ 0.84 A
12V @ 1.66 A
12V @ 2.50 A
12V @ 4.66 A
14V @ 0.18 A
14V @ 0.36 A
14V @ 0.72 A
14V @ 1.44 A
14V @ 2.12 A
14V @ 4.00 A
18V @ 0.14 A
18V @ 0.28 A
18V @ 0.56 A
18V @ 1.12 A
18V @ 1.64 A
18V @ 3.12 A
NOTES: ELECTRICAL SPECIFICATIONS MEASURED AT 25ºC
