Crystal Filter
2 Pole MCF
n
Features
This is a crystal filter that supports surface mounting. Adoption of a ceramic container
has enabled the dimensions of the filter to be 7 x 5 x 1.35 mm. Supports a wide
frequency range.
l
Supports IR reflow and VSP.
(Contact us for information on the temperature profile.)
l
Supports surface mounting. (Packed with embossed tape)
l
Excellent heat- and shock-resistance.
l
Good guaranteed attenuation.
l
Frequency range Fundamental: 20 to 100 MHz, Overtone: 45 to 150 MHz
l
Also supports 3-pole MCF.
(Surface-mount Type)
Pb
Free
n
Specifications
Model
Number of poles
Nominal frequency
3dB Passband width
Stop bandwidth
Ripple
Insertion loss
(insertion attenuation)
Guaranteed attenuation
Spurious characteristics
Terminating impedance
Operating temperature range
Package type
60 dB min.
at –910 kHz
15 dB min.
1500Ω//5pF
–20 to +70°C
NM7050SA
MN15-358
60 dB min.
at –910 kHz
15 dB min.
1500Ω//1pF
–20 to +70°C
NM7050SA
21E15AB-21.4M-
MN15-211
50 dB min.
at –910 kHz
15 dB min.
2500Ω//1.2pF
–20 to +70°C
NM7050SA
21E30AD-21.4M-
MN15-359
60 dB min.
at –910 kHz
15 dB min.
850Ω//6pF
–20 to +70°C
NM7050SA
21E7.5A-21.7M-
MN15-366
60 dB min.
at –910 kHz
15 dB min.
1500Ω//1pF
–20 to +70°C
NM7050SA
21E15AA-21.7M-
MN15-209
50 dB min.
at –910 kHz
15 dB min.
2000Ω//1.2pF
–20 to +70°C
NM7050SA
21E30AF-21.7M-
MN15-365
21E7.5AD
2
21.4MHz
±3.75kHz min.
±12.5 kHz max.
at 15 dB
1dB max.
2dB max.
21E15AB
2
21.4MHz
±7.5kHz min.
±25 kHz max.
at 15 dB
1dB max.
1.5dB max.
21E30AD
2
21.4MHz
±15kHz min.
±50 kHz max.
at 15 dB
1.5dB max.
1.5dB max.
21E7.5A
2
21.7MHz
±3.75kHz min.
±12.5 kHz max.
at 15 dB
1dB max.
2dB max.
21E15AA
2
21.7MHz
±7.5kHz min.
±25 kHz max.
at 15 dB
1dB max.
1.5dB max.
21E30AF
2
21.7MHz
±15kHz min.
±50 kHz max.
at 15 dB
1.5dB max.
1.5dB max.
Code for placing an order
21E7.5AD-21.4M-
Model
Number of poles
Nominal frequency
3dB Passband width
Stop bandwidth
Ripple
Insertion loss
(insertion attenuation)
Guaranteed attenuation
Spurious characteristics
Terminating impedance
Operating temperature range
Package type
45E7.5AB
2
45MHz
±3.75kHz min.
±25 kHz max.
at 20 dB
1dB max.
2dB max.
60 dB min.
at –910 kHz
10 dB min.
200Ω//4pF
–20 to +70°C
NM7050SA
MN15-367
45E15A
2
45MHz
±7.5kHz min.
±25 kHz max.
at 13 dB
1dB max.
3dB max.
70 dB min.
at –910 kHz
10 dB min.
1000Ω//4pF
–30 to +70°C
NM7050SA
45E15A-45M-
MN15-297
45E30AN
2
45MHz
±15kHz min.
±60 kHz max.
at 20 dB
1dB max.
2dB max.
60 dB min.
at –910 kHz
5 dB min.
650Ω//1.5pF
–20 to +70°C
NM7050SA
45E30AN-45M-
MN15-369
90E9A
2
90MHz
±4kHz min.
±50 kHz max.
at 25 dB
0.5dB max.
5dB max.
70 dB min.
at –910 kHz
20 dB min.
200Ω//8pF
2.54
–20 to +70°C
NM7050SA
90E9A-90M-
MN15-226
5.0±0.2
n
Dimensions
NM7050SA
7.0±0.2
1.35±0.15
PAD No PAD CONNECTION
GND
1
GND
2
OUTPUT
3
GND
4
GND
5
INPUT
6
mm
2
1
3
6
–
1.0
2.0
6
–
1.4
Reference land pattern
6
–
2.2
Code for placing an order
45E7.5AB-45M-
6
5
4
6
–
1.2
6.0
cf12_071102_NM7050SA_e1
2.54
