TSX-3225
TSX-3225 (MHz Range Crystal Unit Miniature Size Low Pro le SMD)
Frequency range
16MHz to 48MHz
External dimensions
3.2 × 2.5 × 0.6mm
Overtone order
Fundamental
Applications
Mobile phone, Bluetooth, W-LAN
ISM band radio, Clock for MPU
Parametric Search
Inventory Search
TSX-3225
Brief Sheet
Speci cations
Item
Nominal frequency range
Storage temperature
Operating temperature
Level of drive
Frequency tolerance
Frequency versus temperature
characteristics
Load capacitance
Motional resistance (ESR)
Frequency aging
Symbol
f_nom
T_stg
T_use
DL
f_tol
f_tem
CL
R1
f_age
For RF Reference
16.000MHz to 48.000MHz
-40°C to +125°C
-40°C to +85°C (+105 °C)
200µW Max.
±10 × 10
-6
±10 × 10
-6
/-20°C to +75°C
7pF to
∞
As per below table
±1 × 10
-6
/ year Max.
*1
Condition/Remarks
Fundamental For the out of standard speci cations,
please contact us for inquiries.
Store as bare product.
Please contact us about +85 °C < T_use
Recommended: 1 to 100µW
+25°C For the out of standard speci cations, please
contact us for inquiries.
For the out of standard speci cations, please contact
us for inquiries.
For the out of standard speci cations, please contact
us for inquiries.
-40°C to +8 °C, DL = 100µW
+25°C, First year
*1 40MHz
≤
f_nom : ±2 × 10
-6
/ year Max.
Product name (Standard form)
Motional resistance (ESR)
Frequency
16.0MHz
≤
f_nom < 21.0MHz
21.0MHz
≤
f_nom
≤
48.0MHz
Motional resistance
60Ω Max.
40Ω Max.
External dimensions
(Unit: mm)
