X1G004281008713 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> X1G004281008713

X1G004281008713: DescriptionLVDS Output Clock Oscillator,; CategoryPassive components oscillator; File Size462KB，7 Pages; ManufacturerSeiko Epson Corporation

Download Datasheet Parametric Compare View All

X1G004281008713 Overview

LVDS Output Clock Oscillator,

X1G004281008713 Parametric

Parameter Name	Attribute value
Maker	Seiko Epson Corporation
Reach Compliance Code	unknow
Other features	ENABLE/DISABLE FUNCTION; DIFFERENTIAL OUTPUT; TR, 10 INCH
maximum descent time	0.3 ns
Frequency Adjustment - Mechanical	NO
frequency stability	50%
Installation features	SURFACE MOUNT
Nominal operating frequency	50 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Oscillator type	LVDS
Output load	100 OHM
physical size	7.0mm x 5.0mm x 1.4mm
longest rise time	0.3 ns
Maximum supply voltage	3.63 V
Minimum supply voltage	2.25 V
surface mount	YES
maximum symmetry	55/45 %

Preview

Download Datasheet

View All

Clock OSC

SG7050VAN

SG7050VAN 50.000000 MHz KJBB

Product name

X1G0042810087xx

Product Number / Ordering code

Please refer to the 9.Packing information about xx (last 2 digits)

Output waveform

LVDS

Pb free / Complies with EU RoHS directive

Reference weight Typ. 149 mg

1.Absolute maximum ratings

Parameter

Symbol

Maximum supply voltage

Storage temperature

Input voltage

Min.

-0.3

-40

-0.3

Typ.

Max.

+125

Vcc+0.3

Unit

ºC

Conditions / Remarks

Storage as single product

ST or OE Terminal

Vcc-GND

T_stg

Vin

2.Specifications(characteristics)

Parameter

Symbol

Output frequency

Supply voltage

Operating temperature

Frequency tolerance

Current consumption

Stand-by current

Disable current

Symmetry

Output voltage(LVDS)

Min.

2.25

-20

-50

250

1.15

0.7Vcc

-5

Typ.

50.0000

100

2.6

2.3

21.1

TBD

-88

-118

-140

-151

-154

-157

Max.

3.63

+70

0.0

20.0

450

1.35

150

0.3Vcc

300

Unit

MHz

ºC

x10

-6

Ω

Conditions / Remarks

OE=Vcc L_LVDS=100 ohm

OE=GND

Output load condition(LVDS)

Input voltage

Rise time

Fall time

Start-up time

Jitter

Phase jitter

Phase noise

Vcc

T_use

f_tol

Icc

I_std

I_dis

SYM

Vos

dVos

L_LVDS

t_str

RMS

p-p

acc

L(f)

dBc/Hz

-6

Random Jitter Vcc=2.5V

δ(RMS of total distribution) Vcc=2.5V

Peak to Peak Vcc=2.5V

Off set Frequency: 12kHz to 20MHz Vcc=2.5V

Off set 10Hz Vcc=2.5V

Off set 100Hz Vcc=2.5V

Off set 1kHz Vcc=2.5V

Off set 10kHz Vcc=2.5V

Off set 100kHz Vcc=2.5V

Off set 1MHz Vcc=2.5V

Frequency aging

f_age

x10 /Year

25℃,1stYear

1 Page
