500S48W103KV4H Overview

Large Size Capacitor Chips 50-5,000 VDC

Preview

Download Datasheet

View All

arge

ize

apaCitor

hipS

50 - 5,000 VDC

eatures

•

Rated Working Voltages from 50 to 15,000 VDC

Low ESR Ceramic Out-performs Tantalums

Compact MLC Designs Smaller Than Film or Disc

MIL-PRF-55681 & Hi-Rel Screened Versions Available

Custom Sizes, Voltages, and Values Available

ppliCations

• Power Supplies

• Voltage Multipliers

• Data Isolation

• Surge Protection

• Industrial Control Circuits

• Custom Applications

axiMuM

apaCitanCe vs

dC v

oltage

ating

s49 / 1825

E/B

Inches

.180 ±.010

.250 ±.010

.140 Max.

.025 ±.015

(mm)

(4.57 ±.25)

(6.35 ±.25)

(3.56 Max)

(0.64±.38)

50 V

NPO

X7R

473

185

100 V

383

105

250 V

273

125

500 V

273

334

1K V

153

104

2K V

562

223

3K V

222

822

4K V

102

202

5K V

271

821

s47 / 2220

E/B

Inches

.225 ±.015

.200 ±.015

.150 Max.

.025 ±.015

(mm)

(5.72 ±.38)

(5.08 ±.38)

(3.81 Max)

(0.64±.38)

50 V

NPO

X7R

683

185

100 V

473

125

250 V

333

105

500 V

273

564

1K V

183

184

2K V

682

273

3K V

272

822

4K V

122

332

5K V

391

152

s48 / 2225

E/B

Inches

.225 ±.010

.255 ±.015

.150 Max.

.025 ±.015

(mm)

(5.72 ±.25)

(6.48 ±.38)

(3.81 Max)

(0.64±.38)

50 V

NPO

X7R

753

225

100 V

563

225

250 V

393

125

500 V

333

824

1K V

223

224

2K V

822

473

3K V

472

153

4K V

222

563

5K V

681

222

Available capacitance values include the following significant retma values and their multiples

1.0 1.2 1.5 1.8 2.2 2.7 3.3 3.9 4.7 5.6 6.8 8.2 ( 1.0 = 1.0, 10, 100, 1000, etc.)

ow to

rder

251

VOLTAGE

500 = 50 V

101 = 100 V

201 = 200 V

251 = 250 V

501 = 500 V

102 = 1000 V

202 = 2000 V

302 = 3000 V

402 = 4000 V

502 = 5000 V

S48

CASE SIZE

See Chart

DIELECTRIC

N = NPO

W = X7R

105

CAPACITANCE

1st two digits are

significant; third digit

denotes number of

zeros.

101 = 100 pF

103 = 0.01 µF

105 = 1.00 µF

106 = 10.0 µF

TOLERANCE

J = ± 5%

K = ± 10%

M = ± 20%

Z = +80% -20%

TERMINATION

V = Ni barrier w/

100% Sn Plating

Y = Palladium-Silver

MARKING

4 = Unmarked

3 = Specified

6 = EIA “J” Code

PART MODIFIER

E = 7” Reel Taped

H = High Rel Testing

(Customer Specified)

S = Special Part

Part number written: 630H51W475KY4

www.johanson dielectrics.com
