501645-1020

Description
10 CONTACT(S), MALE, STRAIGHT DIP CONNECTOR, SOLDER, PLUG
CategoryThe connector
File Size30KB,2 Pages
ManufacturerMolexKits
Websitehttp://www.molexkits.com
Download Datasheet Parametric View All

501645-1020 Online Shopping

Suppliers Part Number Price MOQ In stock
501645-1020 - - View Buy Now

501645-1020 Overview

10 CONTACT(S), MALE, STRAIGHT DIP CONNECTOR, SOLDER, PLUG

501645-1020 Parametric

Parameter NameAttribute value
Contact materialsBRASS
Terminal spacing2 mm
Total number of contacts10
Processing package descriptionROHS COMPLIANT
Lead-freeYes
EU RoHS regulationsYes
China RoHS regulationsYes
stateACTIVE
OptionsGENERAL PURPOSE
Shell stylePLUG
Manufacturer Series501645-1020
Contact surface matchingTIN
Contact coated terminalsTIN
Connection TypeDIP CONNECTOR
Connector male and femaleMALE
Installation methodSTRAIGHT
Installation typeBOARD
Number of load rows2
Terminal typeSOLDER
UL flammability code94V-0
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0199
General Information
Part Number:
76650-0199
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
iGrid Connector Kit
Positive Lock Vertical Header and Receptacle
iGrid™
(Molex Parts within this kit) - EU and China RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
iGrid wire-to-board connector system offers a compact design and anti-tangle
internal lock for applications such as gaming machines, appliances, industrial and
other equipment requiring good mating retention. The unique inner lock of iGrid
prevents wire from getting tangled in the latch, compared to outer lock types where
such damage may occur. The internal lock also provides space savings, an audible
click and a robust design to withstand rugged handling.
Features and Benefits
• Compact design saves PCB real estate
• Fully shrouded headers withstand rugged
handling and vibration
• Polarization between housing and terminal
always seats properly in housing
• Internal lock prevents wire tangling; space
saving
Applications
• GPS
• Vending and Gaming machines
• HVAC
• Microwave ovens
• Medical
• Fitness equipment
Wire-to-Board
2.00mm (.079")
Receptacle and Header
Vertical
10,12,14,16 and 18
(1.5 - 2) Amps depending on AWG
250 Volts
26-22 AWG
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
