Datasheet for 76650-0200
General Information
Part Number:
76650-0200
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
iGrid Connector Kit
Positive Lock Vertical Header and Receptacle
iGrid™
(Molex Parts within this kit) - EU and China RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Wire-to-Board
2.00mm (.079")
Connector Type:
Receptacle and Header
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Vertical
20, 22, 24, 26 and 28
(1.5 - 2) Amps depending on AWG
250 Volts
26-22 AWG
Product Highlights
iGrid wire-to-board connector system offers a compact design and anti-tangle
internal lock for applications such as gaming machines, appliances, industrial
and other equipment requiring good mating retention. The unique inner lock of
iGrid prevents wire from getting tangled in the latch, compared to outer lock
types where such damage may occur. The internal lock also provides space
savings, an audible click and a robust design to withstand rugged handling.
Features and Benefits
• Compact design saves PCB real estate
• Fully shrouded headers withstand
rugged
handling and vibration
• Polarization between housing and
terminal
always seats properly in housing
Applications
• GPS
• Vending and Gaming machines
• HVAC
• Microwave ovens
• Medical
• Fitness equipment
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0200
Bill of Materials for Part No. 76650-0200
Molex Part
No.
501647-1100
501646-2000
501646-2200
501646-2400
501646-2600
501646-2800
501645-2020
501645-2220
501645-2420
501645-2620
501645-2820
Country
of Origin
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Description
iGrid™ Female Crimp Terminals, 26-22 AWG
2.00mm (.079") Pitch iGrid™ Receptacles, Dual Row, 20
Circuits
2.00mm (.079") Pitch iGrid™ Receptacles, Dual Row, 22
Circuits
2.00mm (.079") Pitch iGrid™ Receptacles, Dual Row, 24
Circuits
2.00mm (.079") Pitch iGrid™ Receptacles, Dual Row, 26
Circuits
2.00mm (.079") Pitch iGrid™ Receptacles, Dual Row, 28
Circuits
2.00mm (.079") Pitch iGrid™ Vertical Headers Dual Row,
20 Circuits
2.00mm (.079") Pitch iGrid™ Vertical Headers Dual Row,
22 Circuits
2.00mm (.079") Pitch iGrid™ Vertical Headers Dual Row,
24 Circuits
2.00mm (.079") Pitch iGrid™ Vertical Headers Dual Row,
26 Circuits
2.00mm (.079") Pitch iGrid™ Vertical Headers Dual Row,
28 Circuits
Quantity in
Kit
300
2
2
2
2
2
2
2
2
2
2
Recommended Molex Tool(s) for Part No. 76650-0200*
Molex Part
No.
63819-2300 *
Country
of Origin
Description
Sweden
Hand Crimp Tool for 2.00mm(.079") Pitch iGrid™
*Tool(s) not included in kit. Tool(s) ordered separately.
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 2 of 2
