Datasheet for 76650-0150
General Information
Part Number:
76650-0150
Manufacturer:
Title:
Molex / Waldom
Micro Miniature Application Kit
Includes CLIK-Mate, PanelMate, Sherlock, Pico-Spox and MicroClasp Prodcut
Families. Pitches range: 1.25mm (.049") - 2.00mm (.079"). Positive and Friction
Lock.
CLIK-Mate™, PanelMate™, Sherlock™, Pico-Spox™, and MicroClasp™
(Molex Parts within this kit) - EU RoHS Compliant
Kit assembled in U.S.A.
Description:
Product Family:
Certificates:
Country of Origin:
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
Wire-to-Board and Wire-to-Wire
1.25mm (.049"), 1.50mm (.059"), and 2.00mm (.079")
Receptacles, Plugs and Headers
Vertical and Right Angle
2, 3, 4, 6, 8, 9, 12 and 14
1 Amp, 2 Amps, and 3 Amps
30, 50, 125, 250 Volts
(32-30), (30-28), (30-24), & (26-22) AWG
Molex's PanelMate™ series is an ultra low-profile connector system designed for
tight packaging applications. - Molex's new CLIK-Mate™ connectors provide dual
positive locks and a superior audible "click" to help ensure connectors are fully
mated. - The Sherlock™ system utilizes Molex's proven 50212 terminal, along with a
positive lock housing. - Molex's new MicroClasp™ system provides space savings
and easy mating/unmating, plus, includes a unique inner positive lock that provides
latch protection, secure retention and an audible mating "click". - Pico-Spox™
provides Anti-fishhooking box design protects contact area
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 5
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0150
Features and Benefits
• Tuning fork style contact design Secure
contact, and avoids terminal stubbing
• Flat area for pick-and-place Easy automatic
board placement
• Audible "click", low insertion force and
secure mating / Inner positive lock Latch
protection, secure mating, audible "click"
• Box-style contact Protects contact area /
Two-point contact design Secure electrical
contact, High current capable
• Polarizing features Ensures proper mating /
Reinforced metal solder tabs Secure PCB
retention
Bill of Materials for Part No. 76650-0150
Molex Part No.
50641-8141
50753-8141
51146-0200
51146-0600
51146-0900
53780-0270-P
53780-0670-P
53780-0970-P
502438-0100
502439-0400
502439-0600
502439-0800
502443-0470
502443-0670
502443-0870
502494-0470
Country
of Origin
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Description
PanelMate™ Female Terminal 30-28 AWG
PanelMate™ Female Terminal 32-30 AWG
1.25mm (.049") Pitch PanelMate™, 2 Circuit Ultra Low-Profile
Receptacle
1.25mm (.049") Pitch PanelMate™, 6 Circuit Ultra Low-Profile
Receptacle
1.25mm (.049") Pitch PanelMate™, 9 Circuit Ultra Low-Profile
Receptacle
1.25mm (.049") Pitch PanelMate™, 2 Circuit Right Angle
Header
1.25mm (.049") Pitch PanelMate™, 6 Circuit Right Angle
Header
1.25mm (.049") Pitch PanelMate™, 9 Circuit Right Angle
Header
CLIK-Mate™ Male Crimp Terminal 26-22 AWG Loose
2.0mm (.079") Pitch CLIK-Mate™, 4 Circuit Plug Housing
2.0mm (.079") Pitch CLIK-Mate™, 6 Circuit Plug Housing
2.0mm (.079") Pitch CLIK-Mate™, 8 Circuit Plug Housing
2.0mm (.079") Pitch CLIK-Mate™, 4 Circuit Receptacle
Vertical SMT
2.0mm (.079") Pitch CLIK-Mate™, 6 Circuit Receptacle
Vertical SMT
2.0mm (.079") Pitch CLIK-Mate™, 8 Circuit Receptacle
Vertical SMT
2.0mm (.079") Pitch CLIK-Mate™, 4 Circuit Receptacle Right
Angle SMT
Quantity in
Kit
25
25
2
2
2
2
2
2
50
2
2
2
2
2
2
2
Applications
• Appliances White Goods
• Automotive
• Home Applications LCD/PDP TVs Consumer
• Computer Data Communication equipment
Vending and Gaming
• Industrial and Business Equipment Office machines
Medical
• Any application requiring superior mating
assurance
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 2 of 5
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0150
2.0mm (.079") Pitch CLIK-Mate™, 6 Circuit Receptacle Right
Angle SMT
2.0mm (.079") Pitch CLIK-Mate™, 8 Circuit Receptacle Right
Angle SMT
Pico-Spox™ Female Crimp Terminal, Tin (Sn), 24-30 AWG
1.50mm (.059") Pitch Pico-Spox™, 3 Circuit, Vert., SMT,
Header
1.50mm (.059") Pitch Pico-Spox™, 4 Circuit, Vert., SMT,
Header
1.50mm (.059") Pitch Pico-Spox™, 6 Circuit, Vert., SMT,
Header
1.50mm (.059") Pitch Pico-Spox™, 3 Circuit, R/A, SMT,
Header
1.50mm (.059") Pitch Pico-Spox™, 4 Circuit, R/A, SMT,
Header
1.50mm (.059") Pitch Pico-Spox™, 6 Circuit, R/A, SMT,
Header
1.50mm (.059") Pitch Pico-Spox™, 3 Circuit, Receptacle
Housing
1.50mm (.059") Pitch Pico-Spox™, 4 Circuit, Receptacle
Housing
1.50mm (.059") Pitch Pico-Spox™, 6 Circuit, Receptacle
Housing
Female Loose Crimp Terminal 30-24 AWG
502494-0670
502494-0870
87421-0000-C
87437-0343-P
87437-0443-P
87437-0643-P
87438-0343-P
87438-0443-P
87438-0643-P
87439-0300
87439-0400
87439-0600
50212-8100
35507-0300
35507-0400
35507-0600
35362-0350
35362-0450
35362-0650
35363-0360
35363-0460
35363-0660
56134-9100
51353-0800
51353-1200
51353-1400
55959-0830
55959-1230
Japan
Japan
SINGAPORE
2
2
100
2
2
2
2
2
2
2
2
2
100
2
2
2
2
2
2
2
2
2
25
2
2
2
2
2
SINGAPORE
SINGAPORE
SINGAPORE
SINGAPORE
SINGAPORE
SINGAPORE
SINGAPORE
SINGAPORE
SINGAPORE
Japan
KOREA
2.0mm Pitch Sherlock™, 3 Circuit Receptacle Housing
KOREA
2.0mm Pitch Sherlock™, 4 Circuit Receptacle Housing
KOREA
2.0mm Pitch Sherlock™, 6 Circuit Receptacle Housing
KOREA
2.0mm Pitch Sherlock™, 3 Circuit Vertical Header
KOREA
2.0mm Pitch Sherlock™, 4 Circuit Vertical Header
KOREA
2.0mm Pitch Sherlock™, 6 Circuit Vertical Header
KOREA
2.0mm Pitch Sherlock™, 3 Circuit Right Angle Header
KOREA
2.0mm Pitch Sherlock™, 4 Circuit Right Angle Header
KOREA
2.0mm Pitch Sherlock™, 6 Circuit Right Angle Header
Japan
Japan
Japan
Japan
Japan
Japan
MicroClasp™ Female Terminal 26-22 AWG
2.00mm (.079") Pitch MicroClasp™ 8 Circuit Receptacle Dual
Row
2.00mm (.079") Pitch MicroClasp™ 12 Circuit Receptacle
Dual Row
2.00mm (.079") Pitch MicroClasp™ 14 Circuit Receptacle
Dual Row
2.00mm (.079") Pitch MicroClasp™ 8 Circuit Right Angle
Header Dual Row
2.00mm (.079") Pitch MicroClasp™ 12 Circuit Right Angle
Header Dual Row
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 3 of 5
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0150
2.00mm (.079") Pitch MicroClasp™ 14 Circuit Right Angle
Header Dual Row
55959-1430
Japan
2
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 4 of 5
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0150
Recommended Molex Tool(s) for Part No. 76650-0150*
Molex Part No.
63811-7900 *
57352-5000 *
57352-5100 *
63819-2800 *
11-03-0043 *
63811-6400 *
63819-0500 *
57105-6000 *
63811-6300 *
57404-5300 *
57399-6000 *
Country
of Origin
Description
SWEDEN
Hand Crimp Tool , UL Approved - PanelMate™
USA
JAPAN
JAPAN Hand Crimp Tool - PanelMate™
JAPAN Hand Crimp Tool - PanelMate™
SWEDEN
Hand Crimp Tool - (22-26 AWG Terminals) CLIK-Mate™
USA
Extraction Tool - CLIK-Mate™
GERMANY
Hand Crimp Tool - Pico-Spox™
SWEDEN
Hand Crimp Tool - Sherlock™ / Micro-Latch™
USA
Extraction Tool - Sherlock™ / Micro-Latch™
GERMANY
Hand Crimp Tool - MicroClasp™
JAPAN
JAPAN
JAPAN Hand Crimp Tool - MicroClasp™
JAPAN Extraction Tool - MicroClasp™
*Tool(s) not included in kit. Tool(s) ordered separately.
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 5 of 5
