51004-1300 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> 51004-1300

Preview

51004-1300: Description13 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric View All

51004-1300 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	51004-1300	-	-	View	Buy Now

51004-1300 Overview

13 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP

51004-1300 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Total number of contacts	13
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	51004
Contact surface matching	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED
Connection Type	Dual board connector
Connector male and female	Jack
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation type	CABLE
Number of load rows	1
Terminal type	riveting
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0109

General Information

76650-0109

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

MicroBlade Connector Kit

Friction Lock Vertical Header and Receptacle

MicroBlade™

(Molex parts within this kit) - EU RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

Provides a compact and flexible solution for industry standard 2.00mm (.079") pitch

applications such as consumer and small data devices. The MicroBlade system

includes a reliable box-type terminal that provides secure electrical contact, and

headers in straight/right angle entry for design flexibility. The system also includes a

user-friendly friction lock system that includes housing windows to confirm mating.

Wire-to-Board

2.00mm (.079")

Headers and Receptacles

Vertical

5, 6, 9, 11 and 13

2 Amps

125 Volts

30-24 AWG

Features and Benefits

• Compact, low-profile size for space

savings

• Friction lock for good mating retention

• Polarizing features ensures proper

mating orientation

• Straight/Right Angle headers offer design

flexibility

Applications

•DVD players

• Digital video cameras

• Notebook computers

• Office automation equipment

• Automotive

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
