51047-1000 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 51047-1000

51047-1000: Description10 CONTACT(S), MALE, TWO PART BOARD CONNECTOR, PLUG; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric View All

51047-1000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	51047-1000	-	-	View	Buy Now

51047-1000 Overview

10 CONTACT(S), MALE, TWO PART BOARD CONNECTOR, PLUG

51047-1000 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Total number of contacts	10
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Shell style	PLUG
Manufacturer Series	51047
Contact surface matching	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED
Connection Type	TWO PART BOARD CONNECTOR
Connector male and female	MALE
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation type	CABLE
Number of load rows	1
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0125

General Information

76650-0125

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

PicoBlade Connector Kit

Friction Lock Plug and Receptacle

PicoBlade™

(Molex Parts within this kit) - UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

1.25mm (.049") pitch PicoBlade™ system is designed for high-density harness

applications. PicoBlade provides the same 1.0 amperes of current as similar

2.00mm (.079") pitch systems, but in a more compact design. PicoBlade™ is

offered in wire-to-board and wire-to-wire options. The system saves about 45% of

PCB space compared to typical 2.00mm wire-to-board systems. It is a single row

system, available in 2 to 15 circuits, with both surface mount and through-hole

headers.

Features and Benefits

• Reliable terminal for solid electrical

connection

• Friction lock for good mating retention

• Polarizing features ensures proper

mating orientation

• Two solder tabs for better connection

to the PCB

Applications

• Car Radios

• Process controls

• Cash dispensers

• Patient monitors

• Alarm systems

• Set top boxes

• DVD players

Wire-to-Wire

1.25mm (.049")

Plugs and Receptacles

2, 3, 4, 6 and 10

1 Amp

125 Volts

32-28 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2
