51065-0400 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 51065-0400

51065-0400: Description4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

51065-0400 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	51065-0400	-	-	View	Buy Now

51065-0400 Overview

4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE

51065-0400 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Total number of contacts	4
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Shell style	socket
Manufacturer Series	51065
Contact surface matching	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED
Connection Type	Dual board connector
Connector male and female	Jack
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation type	CABLE
Number of load rows	1
Terminal type	riveting
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0114

General Information

Part Number:

76650-0114

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

Micro-Latch Connector Kit

Friction Lock Vertical and Right Angle Header and Receptacle

Micro-Latch™

(Molex Parts within this kit) - EU and China RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

Micro-Latch connectors provide a reliable connection interface for industry standard

2.00mm (.079") wire-to-board applications. The kit includes female crimp terminals,

receptacle housings and semi-shrouded right angle headers. The connector applies

a friction lock mechanism where the noses on the receptacle housings slide into the

header wall openings. This ensures a durable mating and protection of the

electrical circuits.

Features and Benefits

• Uses popular terminals

• Friction lock for good mating retention

• Polarizing features ensures proper

mating orientation

• Surface Mount Component vertical

header is reflow process capable

Applications

• Data Communication Equipment

• Printers/Faxes

• PC's and Monitors

• Automotive

• Home Entertainment

Wire-to-Board

2.00mm (.079")

Receptacle and Header

Vertical and Right Angle

2, 3, 4, and 6

(0.5 - 2) Amps dependent on AWG

125 Volts

30-24 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

51065-0400 Related Products

	51065-0400	51065-0300	53254-0270	57105-6000	76650-0114	63819-0500	51065-0200
Description	4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	2 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER	4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	2 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE
Contact materials	NOT SPECIFIED	NOT SPECIFIED	BRASS	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Total number of contacts	4	4	2	4	4	4	2
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer Series	51065	51065	53254	51065	51065	51065	51065
Contact surface matching	NOT SPECIFIED	NOT SPECIFIED	TIN	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED	NOT SPECIFIED	TIN	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Connection Type	Dual board connector	Dual board connector	TWO PART BOARD CONNECTOR	Dual board connector	Dual board connector	Dual board connector	Dual board connector
Connector male and female	Jack	Jack	MALE	Jack	Jack	Jack	Jack
Installation type	CABLE	CABLE	BOARD	CABLE	CABLE	CABLE	CABLE
Number of load rows	1	1	1	1	1	1	1
Terminal type	riveting	riveting	SOLDER	riveting	riveting	riveting	riveting
UL flammability code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
Shell style	socket	socket	-	socket	socket	socket	socket
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	-	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
