1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0187
General Information
Part Number:
76650-0187
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
Milli-Grid Connector Kit
Shrouded Gold Vertical Header and Receptacle
Milli-Grid™
(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire Size:
Product Highlights
Molex's Milli-Grid family of high density connectors is based on a 2.00 by 2.00mm
(.079 by .079") grid pattern. Compared to traditional 2.54mm (.100") pitch
connectors, Milli-Grid connectors offer up to 40% savings in PCB real estate.
Features and Benefits
• Early entry terminal design for superior
contact
• Locking ramps provide strong retention
force to header
• Fully shrouded to protect pins during
mating/unmating
• Center polarization slot, prevents
mismating
• Locking windows, secures firm locking to
receptacle
• Front latches for added retention forces
after mating
Applications
• Office Automation: Printers, Fax machines,
Scanners, Copiers
• Telecom: Servers, Hubs, Switches, Routers
• Other applications: Vending machines, Gaming
machines, Fitness equipment
• Computer / Peripherals: Disk Drives, Storage,
Servers, Notebook PC, Modems, Motherboards,
Monitors
• Measuring / Analyzing Equipment: Security
systems / alarms, Medical monitoring, Lab
equipment
• Entertainment: Set-top boxes, Car stereos,
Video / DVD products
• Brown Goods
Wire-to-Board
2.0mm (.079")
Receptacles and Headers
Vertical
4, 6, 10; Latching: 14 and 16
(0.5-2) Amps - Dependant on Wire Gauge
125 VoltsDC
30-24 AWG
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0187
Bill of Materials for Part No. 76650-0187
Country
Molex Part No. of Origin
50394-8100-C
51110-0460
51110-0660
51110-1060
51110-1451
51110-1651
87831-0420
87831-0620
87831-1020
87831-1420
87831-1620
Description
2.00mm (.079") Pitch, Milli-Grid™ Receptacle, 4 Circuits,
without Cntr Pol Key,
2.00mm (.079") Pitch, Milli-Grid™ Receptacle, 6 Circuits,
without Cntr Pol Key,
2.00mm (.079") Pitch, Milli-Grid™ Receptacle, 10 Circuits,
without Cntr Pol Key,
2.00mm (.079") Pitch, Milli-Grid™ Receptacle, 14 Circuits,
with Cntr Pol Key, with Latching
2.00mm (.079") Pitch, Milli-Grid™ Receptacle, 16 Circuits,
with Cntr Pol Key, with Latching
2.00mm (.079") Pitch Milli-Grid™ Header, Vertical, Through
Hole, 4 Circuits, 0.38µm (15µ") Gold
2.00mm (.079") Pitch Milli-Grid™ Header, Vertical, Through
Hole, 6 Circuits, 0.38µm (15µ") Gold
2.00mm (.079") Pitch Milli-Grid™ Header, Vertical, Through
Hole, 10 Circuits, 0.38µm (15µ") Gold
2.00mm (.079") Pitch Milli-Grid™ Header, Vertical, Through
Hole, 14 Circuits, 0.38µm (15µ") Gold
2.00mm (.079") Pitch Milli-Grid™ Header, Vertical, Through
Hole, 16 Circuits, 0.38µm (15µ") Gold
Quantity in
Kit
100
3
3
3
3
3
3
3
3
3
3
Singapore
Milli-Grid™ Female Crimp Gold Terminals (30-24) AWG
Singapore
Singapore
Singapore
Singapore
Singapore
Singapore
Singapore
Singapore
Singapore
Singapore
Recommended Molex Tool(s) for Part No. 76650-0187*
Country
Molex Part No. of Origin
63819-0100 *
*Tool(s) not included in kit. Tool(s) ordered separately.
Description
Sweden
Hand Crimp Tool for Milli-Grid™ and MicroBlade Crimp Terminals
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 2 of 2
