51191-0600: Description6 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, RECEPTACLE; CategoryThe connector; File Size30KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

51191-0600 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	51191-0600	-	-	View	Buy Now

51191-0600 Overview

6 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, RECEPTACLE

51191-0600 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Total number of contacts	6
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Shell style	socket
Manufacturer Series	51191
Contact surface matching	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED
Connection Type	Dual board connector
Connector male and female	Jack
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation type	CABLE
Number of load rows	1
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0225

General Information

Part Number:

76650-0225

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

Mini-Latch Connector Kit

Friction Lock Vertical Header and Receptacle

Mini-Latch™

(Molex parts within this kit) - EU and China RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current:

Voltage:

Wire size:

Product Highlights

Mini-Latch connectors provide a reliable interface for industry-standard 2.50mm

(.098" ) wire-to-board applications. The system includes a box-style contact

design and housing-side terminal latch to provide protection to the contact area

during and after assembly. The durable housing also includes guide rails and

molded tabs to facilitate mating and unmating.

Features and Benefits

• Friction lock provides good mating

retention

• Box-style contact protects contact area

• Polarizing features ensures proper

mating

• Guide rails and molded ledges

facilitates mating and unmating

Applications

• Data communication equipment

• Printers and faxes

• PCs and monitors

• Automotive

Wire-to-Board

2.50mm (.098")

Receptacle and Header

Vertical

3, 4 and 6 Circuits

(1.5 - 3) Amps depending on AWG

250 Volts

28-22 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

51191-0600 Related Products

	51191-0600	22-04-1031	50802-9101	51191-0400	76650-0225	51191-0300
Description	6 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, RECEPTACLE	3 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	0.33 mm2, BRASS, TIN FINISH, WIRE TERMINAL	4 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, RECEPTACLE	3 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	3 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, RECEPTACLE
Contact materials	NOT SPECIFIED	NOT SPECIFIED	brass	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Manufacturer Series	51191	35300	50802	51191	35300	51191
Total number of contacts	6	3	-	4	3	3
Options	GENERAL PURPOSE	GENERAL PURPOSE	-	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Contact surface matching	NOT SPECIFIED	Tin OVER Copper	-	NOT SPECIFIED	Tin OVER Copper	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED	Tin OVER Copper	-	NOT SPECIFIED	Tin OVER Copper	NOT SPECIFIED
Connection Type	Dual board connector	Dual board connector	-	Dual board connector	Dual board connector	Dual board connector
Connector male and female	Jack	Pin	-	Jack	Pin	Jack
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	-	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Installation type	CABLE	BOARD	-	CABLE	BOARD	CABLE
Number of load rows	1	1	-	1	1	1
UL flammability code	94V-0	94V-0	-	94V-0	94V-0	94V-0
