SPECIFICATION OF CD SERIES
FEATURES
1. Open Magnetic circuit construction
2. Low cost and high reliability
APPLICATIONS
Notebook , Inkjet printer , Copying machine ,
ADSL modem , Cellular phone , Display monitor ,
Video tape recorder , Video camera , Color TV ,
Lighting and Car electronics.
ORDERING CODE
ORDERING CODE
(1) PRODUCT TYPE CODE AND SIZE CODE
(2) INDUCTANCE
(1) PRODUCT TYPE CODE AND SIZE CODE
(2) INDUCTANCE
(3) INDUCTANCE TOLERANCE (K:±10% , M : ±20%, N : ±30% )
(3) INDUCTANCE TOLERANCE (K:±10% , M : ±20%, N : ±30% )
(4) TUBE
(5) DESIGN CODE
(4) INDUCTANCE HIGH CURRENT RATING
(5) TUBE
CONFIGURATIONS
SHAPE & DIMENSIONS
SIZE CODE
CD268
CD2810
CD2812
CD21012
CD21016
A
(max)
8.5
10.0
10.5
13.0
13.0
B
(max)
12.0
15.0
15.5
17.0
19.0
C
±2.0
15.0
10.0
15.0
15.0
15.0
ΦD
±0.1
0.60
0.65
0.65
0.80
0.80
E
UNIT:mm
±0.5
3.0
5.0
5.0
6.0
6.0
＊Design
as Customer's Requested Specifications.
※All
the data listed in this catalogue are for reference only, King Core reserves the right to alter or revise the specifications without prior notification.
KING CORE ELECTRONICS INC.
Tel:886-3-4698855
Fax:886-3-4691395
No.269,Nanfong Rd.,Pingjhen City,Taoyuan County, Taiwan
E-mail:kc@mail.kingcore.com.tw
Web Site:http://www.kingcore.com.tw
1
CD.A02
RADIAL CHOKE INDUCTORS
→
CD SERIES
ELECTRICAL CHARACTERISTICS
Inductance
ORDERING CODE
(uH)
CD268-4R7MA40U
CD268-6R8MA33U
4.7
6.8
Test Freq
(KHz)
1
1
DC Resistance
(Ω)max
0.040
0.035
Isat
(A)max
4.00
3.30
Irms
(A)max
4.20
3.40
ELECTRICAL CHARACTERISTICS
Inductance
ORDERING CODE
(uH)
CD2810-561MU-01
CD2810-272MU-01
CD2810-302MU-01
CD2810-342MU-01
CD2810-472MU-01
560
2700
3000
3400
4700
Test Freq
(KHz)
1
1
1
1
1
DC Resistance
(Ω)max
1.0
5.1
5.5
6.8
9.7
Isat
(A)max
0.45
0.30
0.30
0.29
0.16
Irms
(A)max
0.80
0.30
0.30
0.29
0.24
ELECTRICAL CHARACTERISTICS
Inductance
ORDERING CODE
(uH)
CD2812-341MU-01
CD2812-342MU-01
340
3400
Test Freq
(KHz)
1
1
DC Resistance
(Ω)max
1.00
8.00
Isat
(A)max
1.00
0.40
Irms
(A)max
0.88
0.27
ELECTRICAL CHARACTERISTICS
Inductance
ORDERING CODE
(uH)
CD21012-701MA093U
CD21012-771MA08U
CD21012-392MA036U
CD21012-432MA035U
CD21012-452MA035U
CD21012-103MA024U
700
770
3900
4300
4500
10000
Test Freq
(KHz)
1
1
1
1
1
1
DC Resistance
(Ω)max
0.81
0.85
4.80
5.20
5.90
12.50
Isat
(A)max
0.93
0.80
0.36
0.35
0.35
0.24
Irms
(A)max
0.90
0.80
0.36
0.36
0.32
0.24
ELECTRICAL CHARACTERISTICS
Inductance
ORDERING CODE
(uH)
CD21016-331MA15U
CD21016-721MA12U
CD21016-781MA10U
CD21016-152MA06U
CD21016-342MA05U
CD21016-452MA045U
CD21016-472MA045U
CD21016-512MA043U
330
720
780
1500
3400
4500
4700
5100
Test Freq
(KHz)
1
1
1
1
1
1
1
1
DC Resistance
(Ω)max
0.40
0.76
0.80
1.70
4.20
6.00
6.00
6.20
Isat
(A)max
1.50
1.20
1.00
0.60
0.50
0.45
0.45
0.43
Irms
(A)max
1.70
1.00
0.90
0.63
0.43
0.35
0.35
0.34
＊Test
Frequency: 1KHz/0.25v
＊Design
as Customer's Requested Specifications.
※All
the data listed in this catalogue are for reference only, King Core reserves the right to alter or revise the specifications without prior notification.
KING CORE ELECTRONICS INC.
Tel:886-3-4698855
Fax:886-3-4691395
No.269,Nanfong Rd.,Pingjhen City,Taoyuan County, Taiwan
E-mail:kc@mail.kingcore.com.tw
Web Site:http://www.kingcore.com.tw
2
CD.A02
