G2-625-CH-P3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> G2-625-CH-P3

G2-625-CH-P3: DescriptionRF Connector, Male, Cable Mount,; CategoryThe connector The connector; File Size216KB，7 Pages; ManufacturerCorning Gilbert Inc

Download Datasheet Parametric View All

G2-625-CH-P3 Overview

RF Connector, Male, Cable Mount,

G2-625-CH-P3 Parametric

Parameter Name	Attribute value
Maker	Corning Gilbert Inc
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	G2, INSERTION LOSS LESS THAN 0.15 DB
Characteristic impedance	75 Ω
Connector type	RF CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
Coupling type	THREADED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
Insertion loss	0.15 dB
MIL compliance	NO
Manufacturer's serial number	G2
Installation method	STRAIGHT
Installation type	CABLE
Maximum operating frequency	1 GHz
Options	GENERAL PURPOSE
Panel mounting	NO
voltage standing wave ratio	1.45

Preview

Download Datasheet

View All

Series 2-Piece

Trunk and

Distribution

Connectors

G2 series 2-piece trunk and

distribution connectors

provide superior performance,

while eliminating the common

disadvantages of traditional

2-piece designs.

• Provides installers a full view of

the cable's center conductor

insertion into the connector

seizing mechanism (no blind

entry)

• Incorporates a patented support

sleeve located in the back nut of

the connector, minimizing cable

"pull back"

• The Tri-Start thread system

(patent pending) minimizes

the required back nut rotations

when tightening the connector

• Domed insulator at the KS

interface prevents moisture

from collecting between the

contact pin and connector body,

reducing the possibility of

corrosion

• Non-rotational design for

installation and disassembly

• The G2 connectors have a

center conductor cutting guide

• Unique closing mechanism

preserves reusability
