1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0129
General Information
76650-0129
Part Number:
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
PicoBlade Connector Kit
SMT Friction Lock Vertical and Right Angle Header and Receptacle
PicoBlade™
(Molex parts within this kit) - UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
1.25mm (.049") pitch PicoBlade™ system is designed for high-density harness
applications. PicoBlade provides the same 1.0 amperes of current as similar
2.00mm (.079") pitch systems, but in a more compact design. PicoBlade™ is
offered in wire-to-board and wire-to-wire options. The system saves about 45% of
PCB space compared to typical 2.00mm wire-to-board systems. It is a single row
system, available in 2 to 15 circuits, with both surface mount and through-hole
headers.
Features and Benefits
• Reliable terminal for solid electrical
connection
• Friction lock for good mating retention
• Polarizing features ensures proper
mating orientation
• Two solder tabs for better connection
to the PCB
Applications
• Car Radios
• Process controls
• Cash dispensers
• Patient monitors
• Alarm systems
• Set top boxes
• Dvd players
Wire-to-Board
1.25mm (.049")
Headers and Receptacles
Right Angle and Vertical
2, 4, 6 and 8
1 Amp
125 Volts
32-28 AWG
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0129
Bill of Materials for Part No. 76650-0129
Country
Molex Part No. of Origin
50058-8000-C
51021-0200-P
51021-0400-P
51021-0600-P
51021-0800-P
53261-0271-P
53261-0471-P
53261-0671-P
53261-0871-P
53398-0271-P
53398-0471-P
53398-0671-P
53398-0871-P
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Japan
Description
PicoBlade™ Crimp Terminal, Female, 32-28 AWG
1.25mm (.049") Pitch PicoBlade™ Receptacle, 2 Circuits
1.25mm (.049") Pitch PicoBlade™ Receptacle, 4 Circuits
1.25mm (.049") Pitch PicoBlade™ Receptacle, 6 Circuits
1.25mm (.049") Pitch PicoBlade™ Receptacle, 8 Circuits
1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,
Right Angle, 2 Circuits
1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,
Right Angle, 4 Circuits
1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,
Right Angle, 6 Circuits
1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,
Right Angle, 8 Circuits
1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,
Vertical, 2 Circuits
1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,
Vertical, 4 Circuits
1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,
Vertical, 6 Circuits
1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,
Vertical, 8 Circuits
Quantity in
Kit
100
5
5
5
5
5
5
5
5
5
5
5
5
Recommended Molex Tool(s) for Part No. 76650-0129*
Country
Molex Part No. of Origin
63819-0400 *
11-03-0043 *
Sweden
Hand Crimp Tool
USA
Extraction Tool
Description
*Tool(s) not included in kit. Tool(s) ordered separately.
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 2 of 2
