53261-0871 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 53261-0871

53261-0871: Description8 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

53261-0871 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	53261-0871	-	-	View	Buy Now

53261-0871 Overview

8 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT

53261-0871 Parametric

Parameter Name	Attribute value
Contact materials	PHOSPHOR BRONZE
Terminal spacing	1.25 mm
Total number of contacts	8
Processing package description	LEAD FREE
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	53261
Contact surface matching	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED
Connection Type	Dual board connector
Connector male and female	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	straight
Installation type	BOARD
Number of load rows	1
Terminal type	surface mount
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0127

General Information

76650-0127

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

PicoBlade Connector Kit

SMT Friction Lock Right Angle Header and Receptacle

PicoBlade™

(Molex Parts within this kit) - UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

1.25mm (.049") pitch PicoBlade™ system is designed for high-density harness

applications. PicoBlade provides the same 1.0 amperes of current as similar

2.00mm (.079") pitch systems, but in a more compact design. PicoBlade™ is

offered in wire-to-board and wire-to-wire options. The system saves about 45% of

PCB space compared to typical 2.00mm wire-to-board systems. It is a single row

system, available in 2 to 15 circuits, with both surface mount and through-hole

headers.

Features and Benefits

• Reliable terminal for solid electrical

connection

• Friction lock for good mating retention

• Polarizing features ensures proper

mating orientation

• Two solder tabs for better connection

to the PCB

Applications

• Car Radios

• Process controls

• Cash dispensers

• Patient monitors

• Alarm systems

• Set top boxes

• DVD players

Wire-to-Board

1.25mm (.049")

Headers and Receptacles

Right Angle

2, 3, 4, 6 and 8

1 Amp

125 Volts

32-28 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

53261-0871 Related Products

	53261-0871	51021-0200	51021-0800	53261-0271	53261-0371	53261-0471	53261-0671	76650-0127
Description	8 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT	2 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	8 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE	2 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT	3 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT	4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT	6 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT	2 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE
Terminal spacing	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm
Total number of contacts	8	2	8	2	3	4	6	2
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer Series	53261	51021	51021	53261	53261	53261	53261	51021
Connection Type	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector
Connector male and female	Pin	Jack	Jack	Pin	Pin	Pin	Pin	Jack
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Installation method	straight	straight	straight	straight	straight	straight	straight	straight
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of load rows	1	1	1	1	1	1	1	1
Terminal type	surface mount	riveting	riveting	surface mount	surface mount	surface mount	surface mount	riveting
UL flammability code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
Contact materials	PHOSPHOR BRONZE	NOT SPECIFIED	NOT SPECIFIED	PHOSPHOR BRONZE	-	-	NOT SPECIFIED	NOT SPECIFIED
Processing package description	LEAD FREE	-	-	ROHS AND REACH COMPLIANT	LEAD FREE	LEAD FREE	LEAD FREE	-
Contact surface matching	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	-	tin	NOT SPECIFIED
Contact coated terminals	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	-	tin	NOT SPECIFIED
