53398-0871 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> 53398-0871

Preview

53398-0871: Description8 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

53398-0871 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	53398-0871	-	-	View	Buy Now

53398-0871 Overview

8 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT

53398-0871 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Terminal spacing	1.25 mm
Total number of contacts	8
Processing package description	LEAD FREE
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	53398
Contact surface matching	MATTE Tin(39) OVER Nickel
Contact coated terminals	MATTE Tin(39) OVER Nickel
Connection Type	Dual board connector
Connector male and female	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	straight
Installation type	BOARD
Number of load rows	1
Terminal type	surface mount
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0126

General Information

76650-0126

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

PicoBlade Connector Kit

SMT Friction Lock Vertical Header and Receptacle

PicoBlade™

(Molex Parts within this kit) - UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

1.25mm (.049") pitch PicoBlade™ system is designed for high-density harness

applications. PicoBlade provides the same 1.0 amperes of current as similar

2.00mm (.079") pitch systems, but in a more compact design. PicoBlade™ is

offered in wire-to-board and wire-to-wire options. The system saves about 45% of

PCB space compared to typical 2.00mm wire-to-board systems. It is a single row

system, available in 2 to 15 circuits, with both surface mount and through-hole

headers.

Features and Benefits

• Reliable terminal for solid electrical

connection

• Friction lock for good mating retention

• Polarizing features ensures proper

mating orientation

• Two solder tabs for better connection

to the PCB

Applications

• Car Radios

• Process controls

• Cash dispensers

• Patient monitors

• Alarm systems

• Set top boxes

• Dvd players

Wire-to-Board

1.25mm (.049")

Headers and Receptacles

Vertical

2, 3, 4, 6 and 8

1 Amp

125 Volts

32-28 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

53398-0871 Related Products

	53398-0871	50058-8000	53398-0271	53398-0371	63819-0400	76650-0126
Description	8 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT	PHOSPHOR BRONZE, TIN (35) FINISH, WIRE TERMINAL	2 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT	3 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SURFACE MOUNT	MOLEX - 63819-0400 - RATCHETING HAND CRIMP TOOL	PHOSPHOR BRONZE, TIN (35) FINISH, WIRE TERMINAL
Contact materials	NOT SPECIFIED	Phosphor bronze	PHOSPHOR BRONZE	PHOSPHOR BRONZE	-	Phosphor bronze
Lead-free	Yes	Yes	Yes	Yes	-	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	-	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	-	ACTIVE
Manufacturer Series	53398	50058	53398	53398	-	50058
Terminal type	surface mount	Wiring terminal	surface mount	surface mount	-	Wiring terminal
