53780-1470

Description
14 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT
CategoryThe connector
File Size32KB,3 Pages
ManufacturerMolexKits
Websitehttp://www.molexkits.com
Download Datasheet Parametric View All

53780-1470 Online Shopping

Suppliers Part Number Price MOQ In stock
53780-1470 - - View Buy Now

53780-1470 Overview

14 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT

53780-1470 Parametric

Parameter NameAttribute value
Contact materialsNOT SPECIFIED
Terminal spacing1.25 mm
Total number of contacts14
Processing package descriptionROHS COMPLIANT
Lead-freeYes
EU RoHS regulationsYes
stateACTIVE
OptionsGENERAL PURPOSE
Manufacturer Series53780
Contact surface matchingNOT SPECIFIED
Contact coated terminalsNOT SPECIFIED
Connection TypeTWO PART BOARD CONNECTOR
Connector male and femaleMALE
collocation informationMULTIPLE MATING PARTS AVAILABLE
Installation methodRIGHT ANGLE
Installation typeBOARD
Number of load rows1
Terminal typeSURFACE MOUNT
UL flammability code94V-0
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0165
General Information
Part Number:
76650-0165
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
PanelMate Connector Kit
Ultra Low Profile SMT Right Angle Header and Receptacle
PanelMate™
(Molex Parts within this kit) - EU RoHS Compliant
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire:
Product Highlights
Molex's 1.25mm (.049") pitch PanelMate™ series is an ultra low-profile connector
system designed for tight packaging applications, requiring profile heights below
2.0mm (.079"). The PanelMate name derives from the original flat-panel LCD
display applications for which it was designed.
Features and Benefits
Applications
Wire-to-Board
1.25mm (.049")
Receptacles and Headers
Right Angle
2, 4, 5, 6, 9 and 14
1 Amp
125 Volts
(32-30) and (30-28) AWG
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 3
