55447-0270 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 55447-0270

55447-0270: Description4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

55447-0270 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	55447-0270	-	-	View	Buy Now

55447-0270 Overview

4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER

55447-0270 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Terminal spacing	1.25 mm
Total number of contacts	4
Processing package description	LEAD FREE
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	55447
Contact surface matching	tin
Contact coated terminals	tin
Connection Type	Dual board connector
Connector male and female	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	straight
Installation type	BOARD
Number of load rows	1
Terminal type	welding
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0138

General Information

Part Number:

76650-0138

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

Mini Mi II Connector Kit

IDT Through Hole Vertical Header and Receptacle

Mini Mi II™

(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

Mini Mi II™ wire harness system is designed for high-density harness applications.

Mini Mi II provides the same 1.5 amperes of current as similar 2.00mm (.079") pitch

systems, but in a more compact design. Molex's Integrated Product Division

provides the new Mini MiII system in both wire-to-board and wire-to-wire options

with different custom lengths and wire configurations enabling multi-branch

harnessing configurations, similar to Molex's existing 2.00mm (.079") pitch MiII

system. The system saves about 45% of PCB space compared to 2.00mm MiII.

Mini MiII is available in 2 to 40 circuits in single/dual row and SMT/through-hole

styles.

Features and Benefits

• 1.5 amps meets office automation

standards

• Internal positive lock for secure retention

• IDT housing for cost effective termination

Applications

• Security devices

• Car audio, car multimedia, car HVAC

• Office equipment

• Set-up boxes

Wire-to-Board

1.25mm (.049")

Through-hole Headers and IDT Receptacles

Vertical

2, 4, 8, 14, 18 and 20

1.5 Amps

100 Volts

28-26 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

55447-0270 Related Products

	55447-0270	55447-0470	55447-0870	55447-1470	55447-1870	76650-0138
Description	4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	4 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER
Contact materials	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Terminal spacing	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm
Total number of contacts	4	4	4	4	4	4
Processing package description	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes
China RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer Series	55447	55447	55447	55447	55447	55447
Contact surface matching	tin	tin	tin	tin	tin	tin
Contact coated terminals	tin	tin	tin	tin	tin	tin
Connection Type	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector	Dual board connector
Connector male and female	Pin	Pin	Pin	Pin	Pin	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Installation method	straight	straight	straight	straight	straight	straight
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of load rows	1	1	1	1	1	1
Terminal type	welding	welding	welding	welding	welding	welding
UL flammability code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
