55450-0869 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Other integrated circuit (IC)> 55450-0869

55450-0869: Description8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT; Categorysemiconductor Other integrated circuit (IC); File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Compare View All

55450-0869 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	55450-0869	-	-	View	Buy Now

55450-0869 Overview

8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0137

General Information

76650-0137

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

Mini Mi II Connector Kit

IDT SMT Vertical Header and Receptacle

Mini Mi II™

(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

Mini Mi II™ wire harness system is designed for high-density harness applications.

Mini Mi II provides the same 1.5 amperes of current as similar 2.00mm (.079") pitch

systems, but in a more compact design. Molex's Integrated Product Division

provides the new Mini MiII system in both wire-to-board and wire-to-wire options

with different custom lengths and wire configurations enabling multi-branch

harnessing configurations, similar to Molex's existing 2.00mm (.079") pitch MiII

system. The system saves about 45% of PCB space compared to 2.00mm MiII.

Mini MiII is available in 2 to 40 circuits in single/dual row and SMT/through-hole

styles.

Features and Benefits

• 1.5 amps meets office automation

standards

• Internal positive lock for secure retention

• IDT housing for cost effective termination

Applications

• Security devices

• Car audio, car multimedia, car HVAC

• Office equipment

• Set-up boxes

Wire-to-Board

1.25mm (.049")

Surface mount Headers and IDT Receptacles

Vertical

2, 5, 8, 14, 18 and 20

1.5 Amps

100 Volts

28-26 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

55450-0869 Related Products

	55450-0869	55450-0269	55450-0569	55450-1469	55450-1869	55450-2069	76650-0137	54596-0510
Description	8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	8 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	5 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, IDC, RECEPTACLE
