55456-1869 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> 55456-1869

Preview

55456-1869: Description12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

55456-1869 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	55456-1869	-	-	View	Buy Now

55456-1869 Overview

12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT

55456-1869 Parametric

Parameter Name	Attribute value
Contact materials	BRASS
Terminal spacing	1.25 mm
Total number of contacts	12
Processing package description	LEAD FREE
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Manufacturer Series	55456
Contact surface matching	TIN
Contact coated terminals	TIN
Connection Type	TWO PART BOARD CONNECTOR
Connector male and female	MALE
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of load rows	1
Terminal type	SURFACE MOUNT
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0139

General Information

76650-0139

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

Mini Mi II Connector Kit

IDT SMT Right Angle Header and Receptacle

Mini Mi II™

(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

Mini Mi II™ wire harness system is designed for high-density harness applications.

Mini Mi II provides the same 1.5 amperes of current as similar 2.00mm (.079") pitch

systems, but in a more compact design. Molex's Integrated Product Division

provides the new Mini MiII system in both wire-to-board and wire-to-wire options

with different custom lengths and wire configurations enabling multi-branch

harnessing configurations, similar to Molex's existing 2.00mm (.079") pitch MiII

system. The system saves about 45% of PCB space compared to 2.00mm MiII.

Mini MiII is available in 2 to 40 circuits in single/dual row and SMT/through-hole

styles.

Features and Benefits

• 1.5 amps meets office automation

standards

• Internal positive lock for secure retention

• IDT housing for cost effective termination

Applications

• Security devices

• Car audio, car multimedia, car HVAC

• Office equipment

• Set-up boxes

Wire-to-Board

1.25mm (.049")

Surface Mount Headers and IDT Receptacles

Right Angle

2, 4, 7, 12, 18 and 20

1.5 Amps

100 Volts

28-26 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

55456-1869 Related Products

	55456-1869	55456-0269	55456-0469	55456-0769	55456-1269	55456-2069	76650-0139	54596-0710	54596-1210
Description	12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	12 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT	12 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, IDC, RECEPTACLE
Contact materials	BRASS	BRASS	BRASS	BRASS	BRASS	BRASS	BRASS	BRASS	PHOSPHOR BRONZE
Total number of contacts	12	12	12	12	12	12	12	12	12
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer Series	55456	55456	55456	55456	55456	55456	55456	55456	54596
Contact surface matching	TIN	TIN	TIN	TIN	TIN	TIN	TIN	TIN	tin
Contact coated terminals	TIN	TIN	TIN	TIN	TIN	TIN	TIN	TIN	tin
Connection Type	TWO PART BOARD CONNECTOR	TWO PART BOARD CONNECTOR	TWO PART BOARD CONNECTOR	TWO PART BOARD CONNECTOR	TWO PART BOARD CONNECTOR	TWO PART BOARD CONNECTOR	TWO PART BOARD CONNECTOR	TWO PART BOARD CONNECTOR	Dual board connector
Connector male and female	MALE	MALE	MALE	MALE	MALE	MALE	MALE	MALE	Jack
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	CABLE
Number of load rows	1	1	1	1	1	1	1	1	1
Terminal type	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	IDC
UL flammability code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
Terminal spacing	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm	1.25 mm	-
Processing package description	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	LEAD FREE	-
China RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	-
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	-
