PD-LD Inc. offers a variety of
packaging options for its’ Near Infra
Red Series of laser diodes. These units
are available in ready-to-use, fiber-
coupled packages, including FC, ST,
and SC receptacles, as well as fiber-
pigtailed units.
The laser diodes offered by PD-
LD are of proven design and
manufacture; the standard wavelengths
are centered at 780nm, 830nm and
980nm. Fiber-coupled CW (continuous-
wavelength) output powers range from
0.1 - 10 mW, depending on the fiber
type and desired performance level.
Devices may be optimized for coupling
to sensor or telecommunication size
optical fiber, from 5um to 200um core.
Optional board- or panel -mount
flanges are available for pigtailed
devices; contact PD-LD Sales. Also,
PD-LD Inc. will package non-standard
lasers or parts specified by a customer
using standard or custom receptacle or
pigtailing techniques. Both receptacle
and pigtail packages are made using an
active micro-positioning system and
proven packaging techniques. Reliable
and efficient devices are produced.
In may case several different pin-
out options are available for similar
wavelength lasers.
PD-LD
Part No.
1
PL78/83/98 Series Near IR Laser Diode Modules
Applications
•
Fiber optic communications
•
Optical Sensing
•
Process Control
•
Test and Measurement Equipment
•
Optical Alignment Systems
•
Medical Apparatus
•
Imaging and Scanning Systems
•
EDFA Modules
Fiber Size and Coupling Efficiency
•
•
•
•
•
5/125um
9/125um
50/125um
62.5/125um
100/140um
8~15%
15~20%
25~30%
30~40%
40~50%
Wavelength (nm)
Min. Typ. Max.
Min. Fiber
Coupled Power
(mW)
0.5mW
into 9/125 SMF
3mW
Into 5/125 MMF
1 mW
into 9/125 SMF
1 mW
ST Recptacle
40 mW
into105/125 MMF
2mW
62.5/125/900um
MMF
10mW into
62.5/125/900um
MMF
3 mW
into 6/125 SMF
Pin-out
Threshold
Operating
Monitor PD
TO Dia Current (mA) Current (mA) Current (mA)
(mm)
Typ. Max. Typ. Max.
Min. Typ.
M
5.6
N
9.0
P
9.0
N
5.6
P
5.6
P
5.6
P
9.0
N
5.6
Continuous Wavelength Lasers @ 25C
770
PL78C0.51FCB-T-0-01
PL78H0037FCD-U-0-01
PL78M001FC11-T-0
PL78R0012STA-0-0-01
PL78T040FC2D-T-0
780
785
800
775
770
770
785
780
785
795
800
795
785
810
35
45
25
25
30
60
70
40
45
50
45
140
40
45
100
70
170
70
65
140
0.1
0.025
0.45
0.3
0.1
0.6
0.15
0.9
0.55
0.25
PL85B0023FCA-0-0-01
830
850
870
5
20
30
45
0.2
0.6
PL83H0103FCA-0-0-01
820
830
840
40 70
80
120
0.04
0.13
PL98A0038FAA-0-0-01
1
965
980
995
5
11
80
100
0.2
0.4
Examples only; most device/packaging combinations available. Changes to specifications may be made without notice.9-08 Near Infra Red series. Rev.D
30-B Pennington-Hopewell Rd., Pennington NJ 08543 FON: 609-564-7900 FAX: 609-564-7901 EMAIL: info@pd-ld.com www.pd-ld.com
PD
Inc
LD
PL78/83/98 Series Near IR Laser Diode Modules
Laser Diode Pin-Out Styles
Ordering Information
Lasers Pigtailed
Laser Receptacle
PLWWWPPPFCCB-0-V-LL
L = Laser
WWW=Wavelength and Pin-out
780nm: 78C,78D,78E, 78H,78M, 78Q,
78R, 78S, 78T
830nm: 83H, 83S
850nm: 85R
980nm: 98D, 98E
PLWWWPPPRRRF-O-V
PPP = Fiber-Coupled Power
0.1
= 0.10 mW (100
µW)
0.8
= 0.8 mW (800
µW)
0.2
= 0.20 mW (200
µW)
001
= 1.0 mW
0.5
= 0.5 mW (500
µW)
040
= 40.0 mW
F = Fiber Type
B = Bracket Type
1 =
9/125 SMF
A
= None
2 =
50/125 MMF
B
= Panel Mount(9mm)
3 =
62.5/125 MMF
D
= Board Mount(5.6mm)
4 =
100/140 MMF
E
= Panel Mount(5.6mm)
7=
5/125 SMF
8=
7/125 SMF
A=
200/240 MMF
D=
105/125MMF
PM Fiber available on request
RRR=Receptacle Type
O=Orientation
FC1=FC Panel mount
0=N/A
FC2=FC Board mount
A=Bracket Shipped Loose (pigtailed unit
SC1=SC Panel mount only Specify orientation as required
SC2=SC Panel/board mount
ST7=ST low profile
V=Version
ST8=ST high profile
0=Standard
Unique Codes for specific requirements
LL = Length in meters
(01,02,.5 ect.) (pigtailed devices only)
CC = Connector Type
(pigtailed devices only)
ST
= ST/PC
SC
= SCPC
SA=SC/APC
FC
= FC/PC
1
FA
= FC/APC
FU
= FC/UPC
OO
= None
Examples only; most device/packaging combinations available. Changes to specifications may be made without notice.9-08 Near Infra Red series. Rev.D
30-B Pennington-Hopewell Rd., Pennington NJ 08543 FON: 609-564-7900 FAX: 609-564-7901 EMAIL: info@pd-ld.com www.pd-ld.com
PD
Inc
LD
PL78/83/98 Series Near IR Laser Diode Modules
Near IR Laser Diodes Available from Stock
PD-LD
Laser Code
78A
78C
78D
78E
78H
78M
78Q
78R
78T
83A**
83H
83S
85B
85C
85D
98D
98E
Nominal Wavelength
(nm)
785+/-10nm
+60°Operation
785nm –15/+25nm
+80° Operation
785nm –15/+25nm
+70° Operation
785nm –15/+25nm
+60° Operation
785nm+/-10nm
785+/-15nm
+60°Operation
785nm –15/+25nm
+60° Operation
785nm –15/+25nm
+60° Operation
785-5/+15nm
830-/+10nm
830-/+10nm
830-/+10nm
850-/+20nm
850-/+20nm
850-/+20nm
975-/+15nm
975-/+15nm
TO Package Size
5.6mm
5.6mm
5.6mm
5.6mm
9.0mm
9.0mm
5.6mm
5.6mm
5.6mm
9.0mm
9.0mm
9.0mm
5.6mm
5.6mm
5.6mm
5.6mm
5.6mm
Laser Pinning
N
M
M
M
N
P
P
N
P
M
P
M
P
M
N
N
N
Maximum Total
Power (mW)*
35.0
5.0
4.0
5.0
50.0
5.0
5.0
5.0
80.0
100
40.0
30.0
5.0
5.0
5.0
100.0
10.0
*The power listed is the total light output from the semiconductor laser chip as measured from the discreet TO package. The
amount of light coupled into the optical fiber will be dependent on the fiber type.
•
Please contact PD-LD Sales to discuss wavelength, pinning and power requirements not listed above.
** The 83A is a Super Luminescent Diode with a 15nm spectral width and 50um coherence length.
1
Examples only; most device/packaging combinations available. Changes to specifications may be made without notice.9-08 Near Infra Red series. Rev.D
30-B Pennington-Hopewell Rd., Pennington NJ 08543 FON: 609-564-7900 FAX: 609-564-7901 EMAIL: info@pd-ld.com www.pd-ld.com
